LAB POINTS

• 4-Deck DJ performance controller designed for Serato
• integrated 4 channel USB audio interface
• familiar 4-channel club mixer design with designated filter knobs and fader start
• 111 MIDI assignable controls - 60 buttons, 7 faders, 7 push encoders, 31 turning knobs, 4 switches, 2 touch-sensitive jog wheels
• ultra-flat XXL jog platters with Vinyl-grip surface
• crossfader curve & assign switches on the front
• mouse-less playlist management control
• versatile controls for effects, smart looping, hot cues and sampler
• stereo RCA input (with phono pre-amp) for hooking up a CD player or turntable with flexible routing control
• mic input
• compatible with every MIDI-learn capable software
• USB bus powered
• 4-deck mapping available for Traktor PRO 2
• includes Serato DJ Intro & 4-Deck Virtual DJ 7 LE

MANUFACTURER'S REVIEW

Reloop is proud to present its first digital mixing controller designed especially for Serato: Terminal Mix 4. By introducing the Terminal Mix 4, Reloop has broken new ground once again with this fully integrated 4-channel mixer offering a wealth of features, including 3-fold EQ with intelligent kill technique and filter modulation capabilities per channel. Any of the 4 channels can be easily assigned to the crossfader via the controls on the front panel, where you will also be able to adjust the crossfader curve.

In addition to the popular Trax Encoder, the master section is now equipped with four convenient management buttons which allow direct access to playlists, crates or further layout views without the need to touch your laptop. This means a desired track can be located and loaded instantly into any deck via the designated load buttons - a fader start* function can also be activated if desired.

As a further highlight, Reloop has developed brand new ultra-flat aluminium jog platters which with an impressive XXL diameter of 15.5 cm have also been enhanced with a non-slip vinyl-grip coating for even more control over your tracks. With a total of 3 modes (Pitch Bend/Vinyl/Quick Search) it's possible to easily switch between pitch correcting, scratching, or browsing through tracks on the fly. The entire transport section is fully equipped with rubberised buttons which offer a comfortable pressure point whilst also being extremely durable.

The performance section features an extensive 8 button layout which can be utilised over 2 separate layers for true versatility. On the first layer 4 hot cues can be fired off and 4 sample decks can be triggered simultaneously. Depending on the software used, other creative possibilities are available, for example the option of accessing hot cues/samples 5-8 on the second layer - or with future software updates this section can be enhanced even further with brand new performance modes (Cut'n'Slice) for live remixing.

The extensive FX section is equipped with 4 buttons, 3 rotary knobs, and 1 endless encoder to provide even more creative possibilities in the mix. The smart loop section also features 4 independent controls allowing users to quickly set beat-precise loops, adjust the size of the loops and even move the loops whilst in a live situation. Reloop also listened to the requests by many DJs and for the first time has integrated a 14 bit pitch fader with 100mm increments, allowing ultra-precise mixing and blending.

The audio section offers a vast array of connecting possibilities for your master PA (including balanced output jacks), a zone function and a DJ booth system. Also very practical are the 2 headphones connections (6.3 mm & 3.5 mm) which can be adjusted with a 1-band equalizer. A microphone connection with a 1-fold EQ for MCs, hosts or singers has also been integrated and can be adjusted via a flexible routing switching system. Furthermore, it's possible to connect a turntable, CD/MP3 player, or iPhone/iPod to the Aux input which can be routed to the master or even software! Terminal Mix comes 'plug and play' ready with Serato DJ Intro and a Virtual DJ 4-Deck LE (Reloop edition). Traktor Pro 2 mappings are also available.

TECH SPECS

• 4 deck USB controller w/ integrated interface and MIDI
• classic 4 channel design
• 1x Pro crossfader with adjustable crossfader curve, 4x volume controllers with Pro line faders
• 4x 3-band EQ, 4x filter knobs
• 2x 15.5cm touch-sensitive, two-part jog wheels for scratching, cueing, etc.
• different jog modes (scratch & pitch bend, quick search)
• 2x high resolution 100mm 14-bit pitch faders without locking position
• 1 assignable encoder, 3 assignable knobs, 4 buttons for effect control
• cue mix, headphones volume, sampler volume and master controllers
• unicoloured, glistening red illumination
• extra large Trax encoder for quick and easy music library browsing (with 4 load buttons)/li>
• 2x 8 bar LED chain (master L+R)
• 6.3 mm microphone input jack with volume and equalizer control
• power house interface: Boost your PA with balanced 6,3mm jack outputs or unbalanced stereo RCA outputs
• stereo RCA booth outputs for extra DJ monitors
• 2 headphones connections: 3.5 mm & 6.3 mm stereo for whatever plug is convenient including equalizer control
• CORE/ASIO drivers with minimum latency and high quality audio characteristics (Mac/PC)
• anti-theft device: Kensington safety slot
• Mac OSX and Windows XP/Vista compatible

COMES WITH

• Serato DJ Intro & Virtual DJ LE 4-deck Reloop edition
• USB cord

LAB POINTS

• high-end DJ controller designed for flexibility and optimal performance with all the most popular DJ programs rather than one program
• true (4) channel layout and easy deck select control
• signature Vestax high-resolution JOG wheels (platters) are highly responsive to touch and can be adjusted to user's touch preference
• large aluminum filter knobs adds a tactile control that borrows from classic DJ mixers
• (2) pad control sections to control loops and samples with 3 banks (levels) of mapping
• low latency, high-resolution 24bit / 48kHz soundcard for top sound quality
• aux input allows you to connect and mix external sources (mic, CD turntables)
• XLR + 1/4" outputs for optimal sound quality

LAB REVIEW

With the VCI-400, Vestax has decided to forgo the software specific hardware design and go for the an all-out controller that is fully customizable and works well with all the most popular DJ programs (Traktor, Serato DJ Intro, Virtual DJ, Abelton, DJay, and more). Vestax has definitely shifted the focus to high quality functionality with enough controls and features to accommodate future software updates.

The VCI-400 does an excellent job in delivering both the flashy deluxe features (lighted pad controls, LED channel meters, wide assortment of controls) and the solid foundational features (high quality jog controls, XLR outputs, excellent soundcard). In addition, the design is very intuitive with all the controls placed seemingly perfectly and marked clearly. Although there is a lot going on, it all makes sense like the placement of the tempo controls with the deck select directly underneath.

OUR OPINION

Although the price point may be barrier for the beginner or novice DJ, we can see this being a longtime workhorse for the working DJ. The feature set eliminates the need for MIDI add-ons and with its high-quality soundcard and XLR outputs, you're ready to plug it into a club system. In addition, we just love the true 4 channel layout, the filter knobs, and the layout (it definitely borrows from a traditional turntable-mixer setup).

KEY FEATURES

• Mic input (XLR/PHONE combo jack) x 2
• Line input (RCA Stereo) x 2
• Master Output： XLR x 2、PHONE x 2
• Headphone output x 1（6.3mm)
• Crossfader curve control x 1
• USB 2.0port (BUS power not supported）
• POWER：DC 7.5V / 1000mA (Power adaptor included)
• POWER CONSUMPTION：4W (AC100V - 230V)
• DIMENSIONS：457(W) × 328(D) × 61(H)mm (including knobs)
• WEIGHT：4.5 kg

COMES WITH

• USB Cable
• SDC-7 pwer adaptor
• Virtual DJ LE 4 Decks
• bundled software MIDI assign guide
• overlays for blank (custom), Serato DJ Intro, Traktro, Virtual DJ LE, Traktor with morea available at Vestaxpro.com

LAB POINTS

• versatile USB MIDI control surface
• same controls and functionality as the OhmRGB but slimmed down for ultra portability
• 81 programmable backlight buttons w/ bi-directional MIDI communication (talk back)
• plug & play USB, no drivers required
• streamlined aluminum construction
• open source software tools to custom edit talk back communication
• single USB connection
• Ohm editor included

MANUFACTURER'S REVEIW

The OhmRGB Slim is a totally customizable, interactive MIDI instrument, designed to give you hands-on control for your performance. High-quality sliders, knobs buttons, and multicolor LEDs provide the interface for creative expression, whether you're mixing samples and synths or DJ'ing a cutting-edge set. The slim model features a streamlined aluminum construction with a custom finish and build quality that is felt down to your fingertips. All of our controllers are proudly hand crafted and assembled for artists by artists in our Austin, Texas shop.

The OhmRGB Slim has bi-directional talkback for communication between the controller and your software. Up to seven colors can be used to create customized layouts and show different states. It's completely USB powered so you don't have to worry about adapters or power strips. It's plug-and-play, so no drivers are required. By removing the MIDI jacks and expansion port, a single USB connection allows this model to slip into your backpack. The OhmRGB Slim works with any software that supports midi and templates are available for many popular softwares such as Ableton Live, Native Instruments Traktor, Propellerhead's Reason and Record, Max/MSP, Max for Live, Renoise, MLRV2, Luminair, Cell DNA, and Arkaos Grand VJ.

KEY FEATURES

• USB Powered, customizable controller
• Multicolored LEDs with Bi-Directional MIDI communication (talkback)
• Class-compliant: no drivers needed for Mac, Windows, or Linux
• 81 Programmable backlight buttons for talk-back and interactive performance
• Programmable MIDI mapping allows you to change the MIDI settings on the hardware
• Aluminum Body with Custom Finish
• Open Source software tools to create your own LED talkback interaction
• Ohm Editor included for MIDI editing, and LED talkback programming
• Made in the USA
• Compatible with any software that supports MIDI learn
• 16" x 9" x 1.25" (WDH) / weight 5 lbs.

OhmRGB vs OhmRGB Slim

• Slim has streamlined casing without wood sidepanels: smaller + lighter
• Slim does not have MIDI IN/OUT or expansion port (it uses USB out instead)

COMES WITH

• USB cable and registration card

LAB POINTS

• robust dj controller with 4 deck control
• includes Traktor LE
• high quality 24 bit/96 kHz audio interface with BurrBrown AD/DA converters
• 90 freely assignable MIDI controls
• stand alone mixer function - analog sources (turntables, CD players, etc) can be connected and mixed without a computer
• sturdy metal construction
• high resolution, ultra slim jog platters with vinyl grip

MANUFACTURER'S REVIEW

First and foremost this controller is perfectly matched to the vast operation of Native Instruments' Traktor PRO and its 4 decks. However, the Jockey 3 is ideally applicable with any other MIDI compatible software, e.g. Virtual DJ.

The ample layout which is optimized for the ergonomic operation methods of DJs, offers intuitive control for a fast and secure performance without the need to touch a computer. The deck-control section is amply equipped and offers ideal control of all advanced functions for perfect digital DJing with up to 4 virtual decks. The newly developed, extremely flat jog wheels with adjustable drag and high resolution with 4096 steps per turn offer unequaled opportunities. Outstandingly precise handling that facilitates control to the split second of every imaginable track during fast-paced club gigs.

Sturdily screwed control dials, extremely smooth-running faders and backlit buttons for visual and tactile status feedback, in full size and club quality, offer every DJ a safe working environment. The solid rubber smooth-touch buttons cater for a direct responsiveness of commands, even after many nightly gigs.

The Jockey 3 is still compact enough for mobile transport and application, a true low-profile, professional controller for the daily club grind of traveling Traktor DJs. Mobile DJs will love the possibility to directly connect their analog equipment, such as turntables or CD players, to the Jockey 3. As opposed to many other solutions on the market, the Jockey 3 offers a true stand alone function that can be operated self sustainingly without a computer - more flexibility is impossible. Thanks to the additional Master Thru connection a second controller can be routed and even monitored; perfect for DJ team setups.

The Reloop Jockey 3 offers a digital mixer section with an exchangeable, extremely smooth-running premium crossfader, sturdy and precise 70mm linefaders, LED level meter, CUE buttons with cue-mix fader, and a high-quality 3-fold EQ. Via metal dip switches -in a classic old school mixer style - two MIDI decks or an analog input can be assigned per channel.

The USB audio/MIDI interface operates with an audio resolution of up to 24 bit/96 kHz on studio standard. The renowned high-end BurrBrown AD/DA converters give the Jockey 3 low latency, first-class sound characteristics, a vast dynamic range, and the necessary power to rock a club. The symmetrical outputs offer powerful sound and in the club they can be routed directly to the sound system. Thanks to the ASIO/CORE driver technology for PC and MAC low latency and first-class sound are guaranteed.

KEY FEATURES

• 4 deck switching system
• high-end 24 bit / 96 kHz audio interface with BurrBrown AD/DA converters and MIDI interface
• stand alone mixing function
• 2x analog inputs with phono/line mode switch
• Adjustable 6.3 mm jack mic input with software/master-routing switching
• 2x headphones connections via 6.3 mm & 3.5 mm jack
• 2x master outputs (symmetrical jack and asymmetrical RCA output)
• 1x booth output for DJ monitor
• Master thru connection for loop-in of a second controller (DJ team) or other source
• 3-fold EQ control plus filter function & gain
• replaceable premium crossfader with adjustable curve
• stable metal construction with bulletproof, 2mm top panel
• 90 freely assignable MIDI controllers (54 buttons, 6 faders, 13 push encoders, 15 control dials, 2 touch-sensitive jog wheels)
• 2 long, high-resolution 14 bit smooth-glide pitch faders for precise matching
• 2 pitch bend buttons
• designated control dials for filter and pan effects
• extensive loop & sample section incl. 4 large CUE/LOOP trigger buttons on 2 banks
• full effect control with 4 ample XL encoders and buttons for impulsive effect action
• perfect beat synchronization thanks to approved Traktor engine incl. iTunes integration
• usable with every other MIDI software, e.g. Virtual DJ
• dual assignment of all elements due to shift layer
• 4 deck control with trigger switches, classic mixer-style
• MIDI turbo mode updates itself each millisecond for ultra fast transmission and status update
• high-resolution jog wheels with up to 4096 impulses per rotation
• jog wheel drag can be adjusted according to one's performance preferences
• large, backlit, rubberized buttons with smooth-touch surface and optimized click point for fast triggering
• System Requirements PC: Windows XP (most recent SP, 32 bit), Win7 (most recent SP, 32 bit/64 bit), Pentium IV / Intel Core 2, 1.8 GHz (we do NOT recommend AMD processors), 2 GB RAM
• System Requirements MAC: OS X 10.5 or higher, Intel Core Duo family (only Intel Macs), 1.66 GHz, 2 GB RAM
• Dimensions: 16.5" x 1.65" x 11.8" mm
• Weight: 4.5 kg

COMES WITH

• Traktor LE
• over 1 GB exclusive Jockey 3 Sample Pack with royalty-free loops, beats, FX and mixing tools (powered by LOOP MASTERS)

LAB POINTS

• designed in collaboration with electronic music pioneer Richie Hawtin
• 8 faders, 24 rotary knobs, 12 pushbutton encoders
• 48 Multicolor LEDs with Bi-Directional MIDI communication
• Programmable MIDI mapping allows you to change the MIDI settings on the hardware
• Aluminum body with an ultra durable black finish
• Open Source software tools to create your own LED talkback interaction
• works with any software (Mac, PC, Linux) with MIDI learn

MANUFACTURER'S REVIEW

CNTRL:R is a contemporary MIDI performance instrument for creative music production. Housed in a lightweight aluminum body, this controller is ideal for live performance and studio production. Create rhythms, sequence and perform drums, launch clips, mix tracks, and have complete control over your performance with CNTRL:R’s advanced set of features. High quality faders, push button encoders, rotary knobs, expression pedal inputs, and keypads backed with RGB lights give you all the controls you need for an interactive performance. With scripts available for Ableton Live and NI Traktor, the CNTRL:R meets the needs of anyone looking to perform electronic music. CNTRL:R is designed and hand crafted in Austin, TX.

CNTRL:R was designed over a one and a half year period with electronic music pioneer Richie Hawtin and the artists on m_nus records. The controller is designed to provide a high quality controller sized small enough to fit into a backpack, but large enough for extensive hands-on control. The instrument has all of the essential controls for music creation and can be adapted to many different software and styles. The “sequencer” section of the controller can be set to create sequences and grooves, or control cue points and triggers. The central 4x4 keypad can launch clips, play drums, and control functions. The fader and knobs are ideal for channel strip controls, device control, EQ, and effects. The CNTRL:R is totally programmable and adaptable to any software that supports MIDI.

TECH SPECS

• USB Powered
• Class-compliant: no drivers needed for Mac, Windows, or Linux
• Standard MIDI IN and OUT jacks
• Expansion Jacks for added functionality
• Made in the USA
• Compatible with any software that supports MIDI learn
• 14.5" x 9.75" x 1.75" (WDH) / weight 5 lbs.

COMES WITH

• USB cable and registration card

LAB POINTS

• DJ USB/MIDI controller with built-in audio interface
• integrated 4 channel USB audio interface with 16 bit/48 kHz
• classic DJ layout ideal for Traktor
• large touch sensitive jog wheels
• RCA out, 1/4" headphone out, 1/4" mic in w/ volume control
• 54 freely assignable MIDI parameters (knobs, faders, buttons)
• includes Traktor LE

MANUFACTURER'S REVIEW

The perfect introduction to digital mixing: based on the famous Digital Jockey series, Reloop presents two new compact controllers that do not accept a compromise when regarding quality and feeling. Clearly structured and well arranged, the DJ will feel comfortable whether newbie or advanced. The feature set is ideally laid out for Traktor LE and offers all the important features for rocking the party crowd! Two touch sensitive XXL jog wheels can be used either for scratching and pitch bending or for quick track searching. With the big transport section (play, cue, cup & sync) the track is quickly mixed and via shift function this section can also be used triggering cue points. Thanks to the precise sync feature every blend-over is perfectly beat-matched and the DJ can focus on more important things such as creative remixing. Effects such as delay, flanger or reverb can be easily selected and manipulated via a large soft-touch encoder. A designated rotary control for filter (and pan) can be used for amazing high-pass and low-pass sweeps (HPF/LPF). The loop section comes with auto loop, manual in & out buttons, and a further encoder for rapid beat looping. The high-resolution 14 bit pitch fader and the illuminated pitch bend buttons round off the player section.

Besides 3-band equalizer and gain the classically arranged 2 channel mixer also offers an LED level meter and convenient MIDI data & power status lights. The large and handy Trax encoder makes digging in the music library and finding just the right track easy as pie. Master and headphones volume and the cue-mix function as high-performance fader are always at hand. On the rear panel the LED background light and the jog wheels sensitivity can be adjusted to one's own preferences. The shift lock switch is also highly practical as it is used to activate the shift function as toggle or hold mode. A further highlight is the DJ Team switch: Two Mixage controllers can be hooked up to one computer. This way one DJ team can control four decks in one software without mixing up the MIDI command (Traktor PRO required).

A pre-configured Traktor LE version is already included; easily connected via USB and selected through the Setup Wizard you are ready to mix. Of course Reloop Mixage is also compatible with any other software that is enabled for MIDI control. Reloop Mixage can be transported easily due to the compact shape and carried effortlessly in every gig bag. This slick controller is characterized by a plain user interface; everybody will quickly get well along with it. High-quality components including sturdy metal panels and a aluminum cover plate are almost unique in this affordable price range. Save your bucks - but don't save on quality! Those who do not possess a multi-channel soundcard should go for the Mixage Interface Edition. A professional multi-channel interface is built in this version. Easily connect your sound system and headphones for direct monitoring of the tracks. The ASIO driver architecture facilitates lowest latency and fast mixing without delay. For hosts, MCs or singers a microphone connection on the front side has been integrated. The signal can be routed directly to the master-out or to a computer for recording; the volume can also be adjusted directly.

KEY FEATURES

• mixer section: 1 x PRO Longlife crossfader, 2 x volume controller with PRO Longlife faders, 2 x 3 band equalizer, 2 x gain knob, 2 x cue button, 2 x LED level meter
• player section: 2 x touch-sensitive (adjustable sensitivity), two-part jog wheels for scratching cueing, large transport section for play, cue, cup, and sync (also useable as cue point section), 2 different jog modes (scratch & pitch bend, fast search), 2 x high resolution 14 bit pitchfader without latch position, 2 x pitch bend buttons, 2 x assignable encoders and 4 x buttons for effect and loop control, designated knobs for filter and pan effect, shift button for double function assignment
• white, red, and orange LED illumination
• cue mix, volume, and master controller
• especially large Trax encoder for quick, easy browsing in the music library (with load buttons)
• power and MIDI data status LEDs
• DJ team mode: change the MIDI channel and connect 2 controllers to a computer for 4 deck control (only with Traktor PRO)
• compatible with Mac OSX and Windows XP/Vista/7
• dimensions: 14.5" x 1.75" x 10"
• weight: 4.2 kg

COMES WITH

• Native Instruments Traktor LE DJ software
• USB cord

LAB POINTS

• USB MIDI hardware controller optimized for Traktor
• 4 channel sound card with 16 bit/48 kHz, external inputs and outputs
• double assignment of MIDI commands with shift buttons
• control up to 4 virtual decks (on Traktor)
• touch-sensitive, two-part jog wheels
• includes Traktor LE

MANUFACTURER'S REVIEW

With the Digital Jockey 2 Reloop gives Traktor DJs a controller that will make sound become truly tangible: A hardware control that facilitates such an immediate access to the world's leading DJ software plus such a great handling of all functions that both components result in a perfect team up.

With its noble panel made of brushed aluminum the Digital Jockey 2 lies so well in the hand as never before. Its control panel is clearly arranged and is geared to all important Traktor PRO functions. The red illumination is very striking, white captions indicate the way to the second MIDI level. Together with the black chassis the Digital Jockey 2 also forms an optical unit with Native Instruments Traktor which is already included as the latest LE version.

DJs that have been working with CD players will feel at ease with the Reloop controller's second generation just as quickly as DJs that have been controlling Traktor via computer. The new, high-quality pitch faders are very delicate and do not lock at 0%.

The Digital Jockey 2's MIDI mapping is enormous: With the glistening white shift buttons a true double assignment of all MIDI commands becomes possible. This way it is possible to control up to 4 virtual decks simultaneously with the Digital Jockey 2 and Traktor.

Additionally the Digital Jockey 2 Interface Edition comes with an outstanding 4 channel sound card with 16 bit/48 kHz that offers a super fast USB connection as well as external inputs and outputs. With the Digital Jockey's Interface Edition 2 it is possible to directly monitor the virtual mixing channel thanks to the headphones input; this way the sound system can also be directly connected by cable to the Interface Edition.

The touch-sensitive, two-part jog wheels are an Interface Edition exclusive that facilitate a vinyl-like feeling when cuing, scratching, browsing and effect modulating. The adjustable knobs on the device's front side for the crossfader curve plus the microphone and headphones equalizers are further additional features of the Interface Edition.

KEY FEATURES

• Professional DJ USB/MIDI controller with integrated audio interface
• Integrated 4 channel USB audio interface with 16 bit/48 kHz
• Stereo RCA inputs (with phono pre-amp) in order to connect CD players and turntables plus 6.3 mm microphone jack (with an equalizer of its own)
• Stereo RCA outputs for the connection of a master sound system and 6.3 mm headphones jack for direct monitoring (with an equalizer of its own)
• Record gain at the device's front side
• ASIO drivers with minimum latency and best audio characteristics
• Optimized for Traktor PRO (clearly arranged shift double assignment, control of up to 4 decks)
• All controllers in full size
• Altogether 73 MIDI controllers (42 buttons, 5 faders, 9 encoders, 6 push encoders, 9 turning knobs, 2 touch-sensitive jog wheels)
• All MIDI controllers are freely assignable
• USB bus power: power supply also possible via USB
• Anti-theft device: Kensington safety slot
• Mac OSX and Windows XP/Vista compatible
• Clearly arranged mixer/CD player design for quick and easy access

COMES WITH

• Native Instruments Traktor LE

OVERVIEW

The VCM-600 is an advanced USB MIDI Controller designed specifically for Ableton Live with genuine Vestax mixer technology to emulate a real multitrack mixing/remixing experience . Includes Ableton Live Lite 7 Vestax Edition so you can start remixing and mixing right out of the box.

FEATURES

The VCM-600 features control of 160 parameters of Ableton Live software and other MIDI compliant DAW software via USB with high quality input faders and pitch faders from the VCI-100 and PMC-580 for advanced operability and performance. Compared to other controllers, the VCM-600 feels extra solid but still light weight with its highly durable aluminum body and genuine Vestax parts. The input faders and crossfader also featuring curve control for the active turntablists and 2 LED panels are placed on each side of the controller to illuminate the top panel for clear view of the controls in dark settings. Includes a special version of Ableton Live Lite designed for seamless operation with the VCM-600. The Vestax Edition of Ableton features 32bit -192kHz audio resolution, 8 tracks of MIDI and audio, 6 scenes, MP3, OGG, FLAC, WAV, AIFF and AAC compatibility, auto warp function, warp multitrack, 24 audio effects, 7 midi effects, 2 software instruments, and more, all in an intuitive interface.

OUR OPINION

If you want a controller that FEELS like a real mixer, you can't beat the VCM-600. While most other controllers may feel too light, plastic-y, or empty, the VCM-600 is solid and performs like a champ with its authentic Vestax parts. While it lacks a large launch button matrix, the traditional mixer layout that matches the Ableton screen will appeal to DJs/Producers looking for a controller that performs great for multitrack mixing. Combined with the included Ableton Live Lite software, the VCM-600 is an excellent all-in-one choice.

KEY FEATURES

• control 160 parameters of Ableton Live software and other MIDI compliant DAW software via USB
• various user assignable knobs, buttons, faders
• multi track control (track bank)
• high quality input faders and pitch faders from the VCI-100 and PMC-580 are also applied to the VCM-600 for advanced operability
• Vestax quality input fader/cross fader with curve control
• simple plug & play activation with Macintosh and Windows operating system computers
• lightweight, high durability aluminum body

INCLUDES

• Ableton Live Lite 7

LAB POINTS

• everything you need to dj (with a laptop) in a compact, all-in-one unit
• multichannel audio system
• master out, monitor, and mic input
• no need for separate audio interface!
• hi-resolution, touch sensitive jog wheels for an analog feel
• onboard EQ, looping, effects, and cue-point control
• high quality faders
• pitch control and instant beat matching
• connects and is powered via USB
• includes Virtual DJ LE, but works with Serato Intro (downloadable for free)

MANUFACTURER'S REVIEW

Typhoon is an all-in-one bundle of digital DJ hardware and software, offering total control to mix, scratch, and play music as a DJ would right at your fingertips. The included software transforms your computer into a full-blown DJ system. Whether for the beginner or seasoned pros alike, plug Typhoon into your computer and you become a DJ.

MULTI CHANNEL AUDIO SYSTEM

For high quality monitoring, master output and separate microphone input.

TOUCH SENSOR JOG WHEEL

Touch sensor jog wheel platters give high resolution to experience an analog feel when scratching and mixing.

EQ SECTION

Easily boost and cut HI, MID & LOW with each frequency knob.

TEMPO CONTROL

Instant beat matching with the sync button and precise adjustment with the speed sliders.

LOOP SECTION

Speedy length setting with the +/- buttons and start a loop at any timing.

SONGLIST

Displays all your tracks with one click.

CURSOR

Move up and down through your song list, push each LOAD button (Left for left deck, right for right deck) to load a song.

EFFECT SECTION

You can instantly add effects to tracks whenever you like and easily adjust the parameters.

FILTER

One push and the jog wheels turn into filter control.

MONITORING

Prepare your next track with clear audio through your headphones by pushing each decks monitor button.

Also features PLAY SECTION that starts & stops songs, CUE/CUP for instant cure point settings, and rugged polycarbonate top panel.

TYPHOON FEATURES

• everything you need to dj (with a laptop) in a compact, all-in-one unit
• multichannel audio system
• master out, monitor, and mic input
• no need for separate audio interface
• hi-resolution, touch sensitive jog wheels for analog feel
• onboard EQ, looping, effects, and cue-point control
• high quality faders
• pitch control and instant beat matching
• connects and is powered via USB
• Dimensions : 14"(W) x 9.5"(H) x 1.5"(D)
• Weight : 1.5kg
• Power Voltage : 5V 500mA
• Power : USB power

VIRTUAL DJ LE FEATURES

• Dual Players with Controls and Pitch
• Internal Mixer with Gain and Equalizers
• Key Lock/Master Tempo
• Instant BPM Detection
• Automatic Beatmatch
• Automatic Gain
• Smart LOOPS

COMES WITH

• USB cable
• CD-ROM (Virtual DJ LE)
• CD-ROM (driver)

LAB POINTS

• ultra-portable software MIDI controller with keys, pads, and knobs
• 25-note, velocity-sensitive mini keyboard
• 8 backlit, velocity-sensitive MPC-style pads (2 banks, 16 total)
• 8 assignable Q-Link knobs to adjust virtually any parameter
• built-in arpeggiator, dedicated octave up/down and sustain buttons
• USB powered

MANUFACTURER'S REVIEW

The Akai Pro MPK mini is an ultra-compact mini-keyboard with an impressive array of buttons, knobs and pads to provide "hands-on" performance and production control no matter your location. MPK mini strikes the perfect balance between portability and comprehensive software control by melding together the complete control offered in the popular Akai Pro MPK family with the grab-and-go convenience of the LPK25 and LPD8. With a 25-note keyboard, 8 back-lit, MPC-style pads and 8 Q-Link knobs, the MPK mini is the ultimate portable controller to get your music moving.

The MPK mini keyboard is ideal for quickly entering notes and phrases into your computer. The velocity-sensitive keys allow you to accurately express dynamics, while accessing different pitch ranges is done instantly through dedicated Octave Up and Down buttons. Create sparkling, staccato leads and driving bass-lines in a variety of time denominations and patterns with MPK mini's built-in Arpeggiator. A Tap-Tempo button gives you the ability to quickly adjust the Arpeggiator clock which is essential if you're looking to stay in sync with a band. A Sustain button holds notes after releasing your hand from the keyboard allowing you the opportunity to easily pound pads and twist knobs, with no pedal required.

MPK mini's 8 back-lit, velocity-sensitive pads are based on Akai Professional's MPC line of iconic music production stations. Great for firing one-shot samples and sequencing drum patterns, you can use the pads to send note information, MIDI CCs, or even program changes. Pressing the Bank button will quickly toggle between 2 banks of pads giving you access to 16 pads in total. Additionally, the MPK mini has 8 assignable Q-Link knobs to control virtually any parameter in your software.

MPK mini works plug-and-play with Mac and PC and requires no software driver installation or wall power for operation. It has four memory banks for programming and recalling settings appropriate to your favorite software programs. The included software editor lets you quickly map MPK mini's controls as well. Recommended.

KEY FEATURES

• 25-note, velocity-sensitive mini keyboard
• Eight backlit, velocity-sensitive MPC-style pads (2 banks, 16 total)
• Pads can send note information, MIDI CCs and program changes
• Eight assignable Q-Link knobs to adjust virtually any parameter
• Built-in Arpeggiator with adjustable resolution, range and patterns
• Tap-Tempo button to quickly adjust pace of the Arpeggiator
• Dedicated Octave Up, Octave Down and Sustain buttons
• Program Recall button to restore up to 4 separate global settings
• Solid Akai Pro design
• Powered through USB; no AC adaptor required

COMES WITH

• MPK mini software editor

LAB POINTS

• 16 expressive MPC pads w/ pressure sensitivity and velocity
• assignable Q-link knobs and faders control up to 12 software parameters
• MIDI over USB with traditional MIDI I/O for controlling software + hardware simultaneously
• MPC Swing to give drum sequences a loose/live feel
• popular MPC-style features: Note Repeat, 16 Level, Full Level, and Tap Tempo
• includes Ableton Live Lite
• easy plug and play on Mac or PC

MANUFACTURER'S REVIEW

The MPD26 is a MIDI-over-USB pad controller with genuine MPC pads. It's perfect for producers, programmers, musicians and DJs. Its blend of intuitive MPC controls and technologies meshes with easy USB connectivity to bring the feel of classic beat making to the world of computer music production.

The heart of the MPD26 is its bank of 16 velocity and pressure-sensitive MPC pads, an Akai Professional exclusive. You can access four different sounds from each MPC pads for a total of 64 at your fingertips. The MPD26 also features the MPC series' assignable Q-Link controllers, enabling you to control nearly any parameters in your software in real time. You get six assignable Q-Link faders and six assignable Q-Link knobs so you'll spend less time with the mouse and more time making music. The MPD26 also gives you a dedicated set of transport controls for instant access to the most commonly used DAW or sequencing-software controls.

While the MPC pads and Q-Links might be the heart of the MPD26, its brain is transplanted directly from the MPC. That's because the MPD26 is not just a control surface; it contains some of the key MPC technologies that have made the MPC the de facto standard it is. MPC Note Repeat is a capability that enables the MPD (or MPC) to automatically play a rhythm pattern, such as 16th notes on a hi-hat, for accuracy and speed of entry. MPC Swing is sometimes referred to as "the heart and soul of hip hop" because it turns perfectly aligned sequences into human-feeling time alignments. You can specify exactly the degree and timing of swing you want to apply for the perfect feel. The MPD26 also has MPC Full Level and MPC 16-Level on its pads.

The MPD26 sends MIDI information over its plug-and-play USB interface so you can use it with your Mac or PC without installing any drivers. The USB connection even powers the MPD26 so the included USB cable is all you need. The MPD26 also has traditional DIN MIDI input and output jacks so you can use it with MIDI hardware such as synths and other sound modules. The MPD26 comes with Ableton Live Lite and Editor Librarian software so you can start creating right out of the box.

The MPD26 is the perfect interface between your creativity and the computer-based studio. Its blend of intuitive MPC controls and technologies meshes with easy USB computer connectivity to deliver the control instrument you need.

KEY FEATURES

• access 64 samples on 16 pressure and velocity-sensitive MPC pads with four banks each
• MPC technologies include Note Repeat, Swing, 16 Level, Full Level, and Tap Tempo
• control virtually any 12 software parameters on assignable Q-Link knobs and faders
• dedicated transport controls transmit MMC and MIDI to DAW and sequencing applications
• MIDI output over USB and traditional DIN MIDI I/O for controlling software and hardware
• Backlit, easy-to-read screen
• USB bus powered, class compliant: plug and play with one USB cable
• comes with Ableton Live Lite and Editor Librarian software

COMES WITH

• USB cable
• Software CD
• Quick start guide

LAB POINTS

• advanced USB controller for Ableton custom designed by Akai and Ableton
• pre-mapped for instant use (but still custom mappable)
• compact version of the popular APC40
• clip launch matrix with multicolor lighting for visual feedback of clip status
• 9 assignable faders
• sturdy metal construction
• USB plug & play, no drivers to install
• includes Ableton Live Lite APC Edition

MANUFACTURER'S REVIEW

Ableton Live software is a powerful, flexible environment for creating, performing, and producing music. This unique software demands an equally unique control instrument. Akai Professional and Ableton are proud to present the APC20 compact professional Ableton Live performance controller. The APC20 transforms your Ableton Live experience from constructing tracks on a computer to fluid, musical creation. The second model in the APC series, the APC20 offers a smaller footprint than the APC40, enabling musicians to more easily create a personalized setup with multiple APCs, effects controllers, and other devices.

The APC20 is the link between human and computer that perfectly balances analytical parameter control with creative expression. Whether you are an electronic music artist and Live is your canvas, a DJ using Live to mix or remix tracks, or a more traditional musician using Live on stage or in the studio, you will find the APC20 to the intuitive, powerful instrument that directly links your inspiration with Ableton Live.

INSTANT PERFORMANCE

Because Akai Professional and Ableton designed the APC20 specifically for Ableton Live, you don't need to map its controls to talk to the software. Just connect your laptop to the APC20 via USB and you're ready to make magic. The APC20 is plug and play, so you don't need to install drivers. First-time setup is literally three steps: load the included Ableton Live software, plug in and power up your APC20, and select the APC20 as Ableton Live's controller. That's it. No mapping, no setup, no hassles.

The APC20 comes pre-mapped for instant use with Ableton Live software, so if you're new to it, you'll find using the APC20 to be easy to get around on. And if you're an experienced Live user, you'll be happy to note that you can custom-map every single button and fader on the APC20 to completely customize the controls for the way you like to work.

VISUAL FEEDBACK

The APC20 talks directly to Ableton Live, and Live talks directly to the APC20. This bidirectional communication makes the APC20 an advanced controller in that it can receive feedback from the software and display it on its Clip Launch matrix. The Clip Matrix gives you an instant view of clip status: what's loaded, what's playing, and what's being recorded. Each state displays in the grid in a different color so you can get a quick picture of clip state. You can shift your clip focus and get an overview of the clips you have loaded for your set.

PROFESSIONAL CONSTRUCTION

Ableton selected Akai Professional as its partner in developing the APC20 because of Akai Pro's leadership position in great-feeling controllers that are rock solid, rugged, and precise. From the legendary MPC series that changed the way music is made to the industry-standard MPD and MPK controllers, Akai Professional is revered by musicians, DJs, and producers everywhere for creating the feel that powers their creativity. The APC20 is built with a rugged, metal chassis and slip-proof rubber detailing. There's no flimsy plastic here. Faders are solid and precise for pinpoint performance.

CREATIVE CONTROL

The APC20 comes with Ableton Live Akai Professional APC Edition software, which is fully functional for performance and production. Owners of the full edition of Ableton Live 8.1.3 or higher can also work seamlessly with the APC20. Live 8.1.3 has full support for the APC20.

The APC20 also enables special clip-status views and feedback that only the APC20's matrix can display. The matrix is not limited to only 40 clips: you can scroll and shift, enabling you to access, control, and perform with an unlimited number of cells.

The APC20 has nine faders, which you can assign to volume control, pan, sends, and a choice of three user-mapped modes. You have even more control power with special controls including Tap Tempo, Tempo Nudge, record enables, and solo/cues. A new User Mode enables you to use the Clip Launch buttons to control instruments and the Drum Rack.

Designed in partnership with Ableton, the APC20 is the ideal controller for performers who like to perform in a small amount of space for maximum portability. It's also perfect for players who want to combine multiple controllers in their setup thanks to its small footprint. Don't settle for cheap, plastic imitations. From the company whose name is synonymous with the word production, the APC20 is the serious choice.

KEY FEATURES

• Designed in partnership with Ableton, mapped for Live, and fully customizable
• Clip Launch matrix with multicolor lighting displays current clip status
• No mapping required; every button and fader is pre-mapped
• Bidirectional hardware/software communication for visual feedback on APC20
• Solid, professional feel with rugged, metal chassis and premium controls
• Comes with Ableton Live Akai Professional APC Edition software
• Works with full editions of Ableton Live 8.1.3 or higher
• USB plug-and-play connection for Mac and PC

OVERVIEW

The MPD32 is a MIDI-over-USB performance pad controller for DJs, programmers, producers, and musicians. Built around the controls and technology from Akai Professional's industry-standard MPC series, the MPD32 is an expressive and intuitive instrument for the studio and stage.

FEATURES

The heart of the MPD32 is its bank of 16 velocity and pressure-sensitive MPC pads. You can access four different banks of sounds from the MPC pads for a total of 64 sounds at your fingertips. The MPD32 also borrows the MPC series' assignable Q-Link controllers, enabling you to control nearly any parameters in your software in real time. You get eight assignable Q-Link faders, eight assignable Q-Link knobs, and eight assignable Q-Link buttons so you'll spend less time with the mouse and more time making music. Even better, each Q-Link can access three different parameters for a total of 72 real-time Q-Links. You also get two assignable footswitch inputs and an expression-pedal input for even more ways to control and perform with the MPD32. The MPD32 also gives you a dedicated set of transport controls for instant access to the most commonly used DAW or sequencing-software controls.

While the MPC pads and Q-Links might be the heart of the MPD32, its brain is transplanted directly from the MPC. That's because the MPD32 is not just a control surface; it contains some of the key MPC technologies that have made the MPC the de facto standard it is. MPC Note Repeat is a capability that enables the MPD (or MPC) to automatically play a rhythm pattern, such as 16th notes on a hi-hat, for accuracy and speed of entry. MPC Swing is sometimes referred to as "the heart and soul of hip hop" because it turns perfectly aligned sequences into human-feeling time alignments. You can specify exactly the degree and timing of swing you want to apply for the perfect feel. The MPD32 also has MPC Full Level and MPC 16-Level on its pads.

The MPD32 sends MIDI information over its plug-and-play USB interface so you can use it with your Mac or PC without installing any drivers. The USB connection even powers the MPD32 so the included USB cable is all you need. It comes with a custom versions of Ableton Live Lite and FXpansion BFD Lite software so you can start creating right out of the box. In addition to Live and nearly any other MIDI software, you can also drive any MIDI hardware, such as synths, sound modules, samplers, sequencers, drum machines, and more. Recommended.

KEY FEATURES

• MIDI controller for production and performance
• MPC pads: bank of 16, velocity and pressure-sensitive
• Four selectable pad banks for a total of 64 sounds accessible from the pads
• Eight assignable Q-Link faders, eight assignable Q-Link 360_ǃ__ knobs, and eight assignable Q-Link buttons, all three banks
• MIDI-synced MPC Note Repeat and MPC Swing
• Two assignable footswitch inputs and expression-pedal input
• Dedicated transport controls
• Backlit, easy-to-read display
• MIDI-over-USB or MIDI operation
• USB powered or powered via optional AC adapter
• MPC 16-Level and Full Level
• Comes with custom versions of Ableton Live Lite, FXpansion BFD Lite, and Vyzor Editor Librarian software
• 30 user-definable presets for DAW applications

COMES WITH

• MPD32 performance controller
• USB cable
• Software CD
• Quick start guide

NOTE: This item is back ordered with the manufacturer until April 2011.

OVERVIEW

Akai's highly anticipated APC40 is finally here! This innovative unit was designed in collaboration with Ableton to be the ultimate USB MIDI controller for Ableton's Live software. It is an unique, intuitive, and powerful instrument that gives total control to the user with over 72 pre-mapped knobs, buttons, and faders - all of which are completely customizable. In addition, the APC40 comes with with Ableton Live Akai Professional APC40 Edition software so you can get started producing right away. This is the most advanced Live controller available.

DIRECT DESIGN

Because Akai Professional and Ableton designed the APC40 specifically for Ableton Live, you don't need to map its controls to talk to the software. Just connect your laptop to the APC40 via USB and you're ready to make magic. The APC40 is plug and play, so you don't need to install drivers. First-time setup is literally three steps: load Ableton Live, plug in and power up your APC40, and select the APC40 as Ableton Live's controller. That's it. No mapping, no setup, no hassles.

The APC40 comes pre-mapped for instant use with Ableton Live software, so if you're new to it, you'll find using the APC40 to be easy to get around on. And if you're an experienced Live user, you'll be happy to note that you can custom-map every single knob, button, and fader on the APC40 to completely customize the controls for the way you like to work.

VIRTUAL VIEW

The APC40 talks directly to Ableton Live and Live talks directly to the APC40. This bidirectional communication makes the APC40 an advanced controller in that it can receive feedback from the software and display it on its clip matrix of 40 triggers and on LED rings surrounding each knob. The clip matrix gives you an instant view of clip status: what's loaded, what's playing, and what's being recorded. Each state displays on the matrix in a different color so you can get a quick picture of clip state. You can shift your clip focus and get an overview of the clips you have loaded for your set. The APC40 has 16 knobs, each surrounded by a ring of LEDs. These LED rings make it easy to see your settings on dark stages, indicating the currently selected parameters' values.

PREMIUM FEEL

Ableton selected Akai Professional as its partner in developing the APC40 because of Akai Pro's leadership position in great-feeling controllers that are rock solid, rugged, and precise. From the legendary MPC series that changed the way music is made to the industry-standard MPD and MPK controllers, Akai Professional is revered by musicians, DJs, and producers everywhere for creating the feel that powers their creativity. The APC40 is built with a rugged, metal chassis and slip-proof rubber detailing. All of the knobs and faders are solid and precise for pinpoint performance. It even features a high quality, replaceable crossfader for transitioning between clips and loops assigned to "A" or "B".

CREATIVE CONTROL

The APC40 comes Ableton Live Akai Professional APC40 Edition software, which is fully functional for performance and production. Owners of standalone editions of Ableton Live 7 or 8 can also work seamlessly with the APC40. Live 7 with the latest automatic update has full support for the APC40 and all versions of Live 8 are APC40-ready.

The APC40 has two banks of eight knobs. The first set controls Global parameters so you'll always have instant access to your main sends, pans, and other essentials. The second bank of eight knobs is dynamically reassigned to the Track you select. You can control eight track parameters at a time, and as you switch channels, the Track knobs follow your focus. For example, you might be working with the Beat Decoder on track two. When you switch to track four, the eight Track knobs that you had been controlling the Beat Decoder with are now controlling the Flangeverb on track four. You'll even notice that the settings for each knob load on the light rings so you'll immediately see each knob's status.

The APC40 also enables special clip-status views and feedback that only the APC40's matrix can display. The matrix is not limited to only 40 clips: you can scroll and shift, enabling you to access, control, and perform with an unlimited number of cells.

The APC40 has a wide range of controllers. The eight Global knobs can access four banks of controls; the eight Track knobs control nine different track parameters each. This gives you a massive total of 72 controllers that are dynamically reassigned each time you switch tracks. Channel faders, bus faders, and a crossfader give you smooth control of key values. You have even more control power with special controls including Tap Tempo, Tempo Nudge, record enables, solo/cues, and two assignable footswitch inputs.

OUR OPINION

This revolutionary controller will definitely change the way you interact with Ableton, in the best ways possible. If you are a performer, DJ, or remixer, this will help you get the most out of Live. Recommended.

KEY FEATURES

• designed in partnership with Ableton for Ableton Live
• unique clip matrix with multicolor lighting displays current clip status
• no mapping required - every knob, button, and fader is customizable
• 8 global
• bidirectional communication between APC40 and Ableton Live
• solid, professional feel with rugged, metal chassis and premium controls
• works with standalone editions of Ableton Live
• USB plug-and-play connection for Mac and PC
• premium controller with rugged, metal chassis
• power supply: 12V 2.0A pin-positive, included
• USB-MIDI with proprietary hardware/software handshake
• inputs: USB, Two assignable footswitch inputs
• dimensions: 16.88" x 13.13" x 2.62" (WxDxH) / 429mm x 334mm x 67mm (WxDxH)
• Weight: 5.8 lbs / 2.64 kg

COMES WITH

• USB cable
• Power supply
• Ableton Live Akai Professional APC40 Edition software

OVERVIEW

The MPK49 is Akai's fully loaded, next generation USB/MIDI controller. It combines 49 high quality, semi-weighted, full size keys (with aftertouch) with 12 genuine MPC drum pads (48 pads total with 4 pad banks). In addition to the keys and pads, a large array of various sliders, knobs and wheels are at your disposal - 76 assignable controls total!

FEATURES

Having USB/MIDI connectivity, 49 high quality, semi-weighted, full size keys (with aftertouch) and 12 genuine MPC drum pads (48 pads total with 4 pad banks) all in one piece is the main draw of the MPK49. The pads themselves not only look and feel just like those on an MPC, but they also feature the MPC's velocity and pressure sensitivity, Full Level and 12 Levels option, Note Repeat, Swing Parameters, and Arpeggio functions. Tap tempo and time-division buttons are also available for real time control of Note Repeat and Arpeggio clock speeds. In addition to the pads there are several other controls including 8 full-sized sliders (with 3 controller banks for each for 24 sliders total), 8 assignable backlit switches (with 3 controller banks each for 24 switches total), pitch bend and mod wheel, and input for expression pedals for a total of 76 assignable controls. A large, easy to read custom LCD display and MMC/MIDI start stop transport buttons are also available.

Also of note is the included Ableton Live Lite Akai Edition software (Mac or PC) which contains 28 custom Akai impulse presets with samples so you can start producing right out of the box.

OUR OPINION

With the genuine MPC pads and control features - the MPK49 is almost like purchasing an MPC and high-end USB controller keyboard in one (for a very reasonable price). In addition - it has ample assignable controls for even the most demanding producers and knob tweekers and is very well equipped to be rocked in the studio or live performance. All this, plus Ableton Live Lite Akai Edition included makes the MPK-49 a top notch choice for anyone looking for a USB/MIDI controller. Recommended.

KEY FEATURES

• 49-key semi-weighted USB/MIDI controller with aftertouch
• 12 genuine MPC pads with velocity and pressure sensitivity
• 72 assignable controls total
• 8 full-sized, 360 degree rotation pots, each with 3 banks for 24 pots total
• 8 full-sized sliders with 3 controller banks for each for 24 sliders total
• 8 assignable backlit switches with 3 controller banks each for 24 switches total
• 2 mod wheels
• MPC note repeat and all-new arpeggiator
• tap tempo and time division buttons
• assignable inputs for expression pedal, footswitch, pitch and mod wheel
• MMC/MIDI Start Stop transport buttons
• large, easy-to-read custom LCD display

COMES WITH

• Ableton Live Lite Akai Edition - contains 28 custom Akai Impulse presets with samples (for MAC or PC)
• USB Cable

LAB POINTS

• low-profile, 25-key USB-MIDI keyboard
• ultra compact size ideal for use with laptop and netbook computers
• advanced-design keybed offers improved accuracy and velocity-sensitive keys
• sustain button - ideal for entering piano parts
• control buttons provide simple yet versatile control
• USB power for an uncluttered setup

MANUFACTURER'S REVIEW

The nanoKEY2 features an advanced and up-to-date design. By combining the great-feeling "touch" that Korg has developed for its professional MIDI keyboards and the low-profile "thinness" of recent computer keyboard innovations, the nanoKEY2 provides a superior keyboard response for its class and size. It's designed with ample key width and plenty of space between the keys, reducing the chances of a wrong note. The touch and velocity response have been carefully tuned, as only a manufacturer with Korg's track record and know-how can, ensuring that your expressive performance will be conveyed accurately to your software.

The Octave Shift buttons - borrowed from Korg's MIDI controllers - allow the overall pitch to be shifted four levels, either UP or DOWN, in octave increments. For enhanced performances, the nanoKEY2 also provides Pitch Bend buttons, a Modulation button, and a Sustain button, one that's indispensible for piano or electric piano performance. For each of these buttons, the on/off switching speed can be specified over four levels (using the Korg Kontrol Editor), ensuring the smooth changes that are appropriate for your performance.

The nanoKEY2 works with the "Korg Kontrol Editor" software, available free on the Korg website. Load it into your computer, and use it to make detailed customized settings. Choose from a total of four velocity settings: three velocity curves or fixed velocity; specify the control change messages transmitted by the modulation button and the sustain button.

Just connect a single USB cable from your computer to the nanoKEY2, and you've got a quick and portable music production system. Power and USB-MIDI data travels down the same wire for a clean, efficient workspace.

KEY FEATURES

• Keyboard: 25-key with velocity and 4 velocity curves
• Pitch up/down buttons
• Octave Shift up/down buttons with -4 to +4 octave range
• Modulation button
• Sustain button
• mini-USB connection
• USB bus powered
• Size (W x D x H) 12.80 x 3.27 x 0.65 inches
• Weight: 0.54 lbs.

COMES WITH

• USB cable

OVERVIEW

The VFX-1 is a dedicated USB effects control unit for use when DJing with the Vestax VCI-300 and ITCH.

FEATURES

The VFX-1 features 2 individual effect channels with 12 effects each (including flange, phase, HPF, LPF, echo, delay, reverb, crusher, tremolo, user 1-2-3), along with 3 large rotary control knobs to control the parameters for each effect. Each effect can then be fed into deck A or B, Master or even the AUX/Mic. A maximum of 3 parameters are adjustable for each effect and the BEATS knob instantly sets the beat ratio of the effect time in sync with the songs BPM (beats per minute) - alternatively you can use the TAP TEMPO to manually set the time. The VFX-1 uses a simple USB connection with your computer and runs with the power provided. Connecting the VCI-300 and VFX-1 together will activate the effect unit of serato ITCH with no special settings or installation required. Works with both VCI-300 and VCI-300MKII.

KEY FEATURES

• 2 separate effect channels
• 12 selectable effects (flange, phase, HPF, LPF, echo, delay, reverb, crusher, tremolo, user 1-2-3)
• 3 adjustable parameters per effect
• auto BPM or tap tempo
• large rotary knob for precise parameter control and feel
• selectable effect ON/OFF mode (Momentary & Latch)
• soft touch buttons
• Compatible with VCI-300/VCI-300MKII and ITCH controller products

LAB POINTS

• all-in-one hardware + software digital djing system, all you need is a computer and headphones
• custom designed to use with Serato Itch program (included)
• designed with djs in mind, increasingly more popular amongst digital djs
• built-in interface, easy setup, no need for additional Serato box or audio interface
• dedicated USB MIDI controller
• highly portable, weighs less than 9 lbs.
• touch sensitive JOG wheels simulate real turntable control

OUR OPINION

This is the updated MKII version. Main differences between MKI and MKII: small 1/8" and big 1/4" headphone socket, master volume boost when using an external power supply, new adjust knobs for the platter sensitivity, new optional Vestax digital crossfader, and new analog throughput for mic/aux input.

The VCI-300 is quickly becoming the dj standard for all-in-one, controller based DJing. The intuitive mixer-like layout, the touch sensitive JOG wheels, and the Serato Itch software, all combine to give the user an experience that is very similar to djing on a turntable-based Serato setup. We've seen many DJs use the VCI-300, and everything from the djs movements to the music manipulation is very similar. In addition, because of its size, weight (less than 9 lbs.), and all-in-one design (the interface is built-in), the VCI-300 is one of the most portable djing solutions available. Recommended.

MANUFACTURER's REVIEW

Vestax and Serato have joined forces. Sharing their technology and compiled feedback from Pro DJs and users from around the world, they have created a dedicated DJ USB MIDI / Audio system and software offering absolute control.

The VCI-300 is a dedicated USB MIDI controller for the included Serato DJ software. It also comes with a built in audio interface with standard 4in/4out and headphone connection, which means all you need for DJing is the VCI-300, a laptop and a set of headphones.

New features such as the [Emergency Thru Switch] offers an option of using the VCI-300 with the provided ITCH software or without the computer connected if you simply want to play music from your external CD or MP3 player. Another is the new weight reduced JOG wheel and the adjustable JOG wheel torque mechanism to avoid vibration from low frequency feedback.

HIGH RESOLUTION CONTROL

The VCI-300 can control more than 90 parameters and functions of the included Serato software with high resolution MIDI signals sent via USB. The pulse resolution of the JOG wheel and pitch control fader is 4 times higher than the VCI-100 and provides precise control of each function. The pitch control fader also shares the same high quality fader parts of the input fader for advanced operability.

SUPERB AUDIO CHARACTERISTIC

The built-in audio interface carries a Audio Codec IC with superb audio characteristic, generated by a delta-sigma modulation 24 bit stereo D/A-A/D converter. Audio connection includes 1 stereo input, 1 MIC input and 2 stereo output (Master L/R, Monitor L/R).

LEVEL INDICATION

A 12 level LED L/R indicator is set in the center of the top panel to monitor sound levels.

FILE CONTROL

Audio files in the software library can be easily selected and controlled with the CRATES / FILES / BROWSE key and the cursor switch inherited from the VCM-100.

EMERGENCY THRU SWITCH

The Emergency Thru Switch located on the rear panel is a countermeasure where you can use the VCI-300 with the provided ITCH software or without the computer connected if you simply want to play music from your external CD or MP3 player. The ITCH software reads music from your iTunes library or the Serato library you use for Scratch LIVE, making it the perfect device for recreational or professional DJ's.

ADJUSTABLE JOG WHEEL TORQUE

The torque of each JOG wheel can be adjusted to prevent them from moving from low frequency feedback and altering the pitch when using the VCI-300 in such places like clubs.

FADER CURVE CONTROL

The fader curve of each fader can be adjusted to the preferred characteristics for long mixes, scratching and any other style.

KEY FEATURES

VCI-300 Specs

• works with MAC and PC, please see manufacturer's link for specific computer requirements
• USB bus-powered
• (2) 1/4" master outputs
• (2) RCA master outputs
• (2) RCA AUX inputs
• (1) mic input
• (1) headphone output
• crossfader with curve control
• 410(W) x 43(H) x 275(D)mm, 8.5 lbs

Serato ITCH Specs

• High performance portable music system that allows internal mixing and platter style playback control.
• Integrated "one to one" hardware to software mapping for instant control and minimum setup time.
• Interoperable with Scratch LIVE crates, loops and cue points, also support for iTunes.
• Audio processing and internal mixing via Serato ITCH software, Channel fading, EQ, cross fading and track trim are processed in software with audio and headphone monitoring on the ITCH hardware.
• Clean and simple software user interface with emphasis on hardware controller to display information.
• Auto Tempo Matching and Beat Sync.
• Optimal Gain and BPM Calculation.
• Serato's unique color waveforms for easy identification of sound.
• Set and store Cue-points.
• Manual and Auto Loop activation.
• Music Library management tools for backup and restore.
• Input and Mix recording capability.
• AIFF, WAV, MP3 and AAC audio file support.

COMES WITH

• Serato ITCH Software

LAB POINTS

• advanced touchstrip controller with 2 and 4 deck control
• built-in 2 in 4 out USB interface w/ high level outputs
• 2 x 8 banks oflarge trigger pads for hot cues, looping and slicing
• Slicer Mode chops tracks into slices for live remixing without falling out of sync
• auto beat sync with ITCH or mix manually with touchstrips
• familiar mixer layout with on-board FX control
• hard-wearing metal surface, compact portable design
• includes Serato Itch
• can be mapped to any MIDI compatible software (Traktor Pro, Ableton)

MANUFACTURER'S REVIEW

Novation TWITCH is a DJ controller with a completely new take on DJing. The worlds of digital DJ and Controllerism are colliding; performers are looking for new ways to manipulate music. Instead of simply mixing tracks together with 'decks in a box', TWITCH re-focuses on cutting up beats, glitch-esque looping, firing off cue points and getting a totally different level of control over FX.

TWITCH has been co-developed with Serato and comes with ITCH DJ software, which is ultra-stable and has some powerful performance features, including the ability to beat-match your tracks so you can do some incredible remixing in real-time without falling out of sync.

For more details, please visit the manufacturer's website.

KEY FEATURES

• touchstrips allow for quick control and swiping of tracks
• ultra-reliable 2 in 4 out USB-audio interface: plug straight into monitors, mixer or amp
• professional, high level outputs which eliminate hum and noise
• microphone input: with independent analogue gain control
• second stereo input: aux input with its own analogue gain for iPods or other sound sources
• Custom audio/MIDI drivers: ultra-low latency audio/MIDI drivers by Novation
• Outputs 24bit at sample rates of 44.1/48KHz
• LED backlit buttons: essential for performing in dark environments
• fully bus powered: easy to set up and no need for additional power supply
• powerful headphone amp

COMES WITH

• Serato Itch
• Traktor Pro overlays

LAB POINTS

• palm-sized cue point and looping controller
• fits on your turntables, CDJs, mixer, or laptop for easy access to controls
• backlit, multi-colour, soft touch "dice" buttons, provide immediate LED feedback
• pre-programmed for cue point and looping functions in Serato
• fully MIDI mappable for use with any DJ software
• plug and play, USB powered

MANUFACTURER'S REVIEW

Developed with Serato, this palm-sized cue point and looping controller has been designed to fit exactly where you need it: on your turntables, CDJs, mixer or laptop. Dicer always ships in pairs - one for each side. Plug Dicer in, slot it on your turntable/CDJ, and you can instantly set cue points and use them to trigger 'Hot Cues'. Or, flip Dicer into 'Auto-Loop' or 'Loop Roll' modes, to trigger loops, or 'roll' sections of the track to create climaxes, drops and glitchy breaks. Each 'mode' illuminates Dicer's pads a different colour, so you can instantly see what mode the pads in, even in dark clubs and venues.

Serato Scratch Live 2.1 will automatically map the Dicer to these functions and provide full LED feedback - red for Hot Cues, green for Loop Roll, and amber for Auto-Loop.

Dicer's buttons can also 'learn' other software functions. So, you can assign different FX to the pads, or trigger samples over the top of your mix, or even browse tracks in your iTunes library!

Dicer was designed by Novation in collaboration with Ean Golden - DJ and curator of DJ Tech Tools. Ean came up with the concept of a controller that fits on the turntable, and his contribution has been crucial in helping Novation design and develop Dicer.

Dicer does not come with its own software, it works in conjunction with Serato Scratch Live or other DJ software such as Traktor Scratch Pro.

For more details, please visit the manufacturer's website.

KEY FEATURES

• palm-sized cue point and looping controller designed to fit on your turntables, CDJs, mixer, or laptop
• backlit, multi-colour, soft touch "dice" buttons, provide immediate LED feedback
• locks straight onto Technics SL 1200/10, and similar decks Using the 45-adapter hole
• attaches to CDJs, mixers and laptops with Novation's reusable DJ putty
• pre-programmed for cue point and looping functions in Serato Scratch Live, including Hot Cues, Auto Roll and Loop Roll
• fully MIDI assignable, works with all major DJ software
• USB bus-powered
• plug and play, no need to install any drivers
• shipped as a pair

OVERVIEW

The LaunchPad is an innovative USB controller custom designed for composition and performance in Ableton Live. With it 8x8 multi-color 64-button grid and dedicated scene launch buttons, Launchpad is purpose built for triggering and manipulating clips in Live. Empowered with Novation's unique Automap software, it can work to control almost any music/production software. It even includes a special "LaunchPad Edition" of Ableton Live 8 providing everything you need to start producing and performing in Live.

FEATURES

LaunchPad features a 64 button lighted grid and dedicated scene launch buttons that mimic the clip layout of Live. There are also volume, pans, sends, track aiming, solo, and muting available for all 8 channels at one with bi-directional communication between the unit and Live software via USB. The automap feature makes setup easy and also allows you to connect the LaunchPad to other software. You can even link up 6 LaunchPad units at the same time for 384 buttons of control! In addition, the unit comes packed with a special "LaunchPad Edition" of Ableton Live 8 providing all the essentials you need to compose and perform, plus 1GB of Loops from Loopmaster, 500MB of high quality drum samples from Mike the Drummer so you can get jamming right away.

OUR OPINION

The LaunchPad is an excellent controller for Live users. It's simple and intuitive layout works perfectly with Ableton's workflow and it comes at a very competetive price (much more affordable than many other options). It is also considerably smaller than popular units like the APC40 making it easier to transport to gigs. Recommended.

KEY FEATURES

• designed in partnership with Ableton for seamless operation
• 64 button lighted grid and dedicated scene launch buttons
• volume, pans, sends, track aiming, solo, and muting
• for all eight channels at once
• bi-directional communication between unit and LIVE
• use up to 6 LaunchPads at a time
• compatible with automap and other controllers
• works with Mac and PC

COMES WITH

• Ableton Live 8 LaunchPad addition
• 1GB Loopmasters collection
• 500MB of Mike The Drummer Samples
• USB cord

LAB POINTS

• low-profile pad controller, excellent for playing or entering drum data
• ultra compact size ideal for use with laptop and netbook computers
• 16 solid, responsive, and velocity-sensitive trigger pads
• numerous assignable knobs, sliders, and buttons
• dynamic trigger pads capture all your performance nuances
• control multiple MIDI parameters via the X-Y Touchpad
• USB power for an uncluttered setup

MANUFACTURER'S REVIEW

Like all nanoSERIES2 controllers, the nanoPAD2 had to be compact, lightweight and sized to work well with any laptop or desktop computer. In addition, the nanoPAD2 also had to pack in 16 great-feeling and dynamic-sensing pads, as well as leaving room for the X-Y touchpad! The Korg nanoPAD2 does all this and more. In fact, there are four banks of pad assignments, providing a total of 64 pad assignments.

The sixteen velocity-sensitive pads provide excellent response to your fingertips, and also realistically convey the playing feel to your sequencer or DAW software, ensuring that your drum parts will be full of life. By switching between the four scenes, you can experience 64 different pad assignments.

The X-Y pad can be used to control multiple synthesizer parameters. In addition, the new "Touch Scale" function lets you intuitively play phrases on the X-Y touchpad, just as on the Kaossilator. You can choose from sixteen different scales, and specify the root key and note range to ensure that your performance stays within your song. The "Gate Arp" function, borrowed from the Kaossilator Pro, transmits note data based on tempo; Tap tempo and tempo sync are supported. Combined with the Touch Scale, the Gate Arp allows you to play tempo-synchronized phrases and rhythms simply by stroking the X-Y pad or playing the pads.

The nanoPAD2 works with the "Korg Kontrol Editor" software - available free on the Korg website. Load it into your computer, and use it to make detailed customized settings. Choose from a total of four velocity settings: three velocity curves or fixed velocity. You can also specify note numbers, create user scales for the Touch Scale function, assign chords, assign control change messages, and save your settings.

Just connect a single USB cable from your computer to the nanoPAD2, and you've got a quick and portable music production system. Power and USB-MIDI data travels down the same wire for a clean, efficient workspace.

KEY FEATURES

• 16 trigger pads with velocity and 4 velocity curves
• X-Y pad
• HOLD button
• GATE ARP button
• TOUCH SCALE button
• KEY/RANGE button
• SCALE/ARP button
• SCENE button
• 4 user scene memories
• mini-USB connection
• USB bus power
• Size (W x D x H): 12.80 x 3.27 x 0.63 inches
• Weight: 0.63 lbs.

COMES WITH

• USB cable

LAB POINTS

• low-profile, multi-function control surface
• ultra compact size ideal for use with laptop and netbook computers
• new track select and marker advance parameters
• numerous assignable knobs, sliders, and buttons
• supports most popular software titles including major DAW programs
• USB power for an uncluttered setup

MANUFACTURER'S REVIEW

In a body proportioned to fit perfectly in front of your laptop computer, the nanoKONTROL2 provides eight channels of the controllers you need to control your music software. The nanoKONTROL2 also features a dedicated transport control section. The buttons have been carefully selected to be useful with your software, ensuring simple and intuitive control. Many software titles - including major DAW programs - are supported, dramatically reducing the need to make complicated connection settings.

A knob, fader, and three switches are provided for each of the eight channels, respectively assigned to pan, volume, and solo/mute/record. This arrangement is a real convenience when recording automation for multiple channels. There's also a marker button, making it easy to assign marks at important points in your song for more efficient recording and song production. When using a software synthesizer, you can assign parameters to the desired controllers for easy control. For example you could use the faders to control the ADSR of an envelope generator, and use the knobs to control the filter's cutoff frequency and resonance, etc.

The nanoKONTROL2 works with the "Korg Kontrol Editor" software - available free on the Korg website. Load it into your computer, and use it to make detailed customized settings. For example, the minimum and maximum values for each control change message can be specified.

Just connect a single USB cable from your computer to the nanoKONTROL2, and you've got a quick and portable music production system. Power and USB-MIDI data travels down the same wire for a clean, efficient workspace.

KEY FEATURES

• 8 knobs
• 8 sliders
• 24 buttons
• Transport buttons: REW/FF/STOP/PLAY/REC
• CYCLE button
• MARKER button
• TRACK button
• works with Avid Pro Tools/Apple Logic, GarageBand/MOTU Digital Performer/Steinberg Cubase/Ableton Live/Cakewalk
• mini-USB connection
• USB bus power
• Size (W x D x H): 12.80 x 3.27 x 1.18 inches
• Weight: 0.65 lbs

COMES WITH

• USB cable

LAB POINTS

• USB MIDI keyboard w/ velocity-sensitive minikeys
• thin and lightweight
• dual USB port to add other USB controllers
• pitch bend, mod wheel, octave and key transpose

MANUFACTURER'S REVIEW

The microKEY is slim, lightweight, USB powered and compatible with all of your computer music software; use it to create your own compact and customized command center.

Natural Touch mini keyboard

The microKEY features 37 velocity-sensing mini keys, using the same Natural Touch keybed found on the Korg microKORG XL and microSTATION. This keybed has been designed with careful attention to the touch and feel. The proportions of the black keys and white "waterfall" keys have been adjusted for optimal playability, and the key touch makes it easy to play chords, glissandos, and rapid-fire phrases. The microKEY accurately conveys the dynamics of your performance to any software plug in.

Extended Range and Expression

The Octave Shift buttons extend the range of the microKEY by four octaves in either direction: up or down. The Key Transpose allows you to play in any key instantly. Used together, these two features provide access to the entire MIDI note range. For adding tasty expression to your performance, the microKEY is also equipped with both a Pitch Bend wheel and a Modulation wheel.

USB versatility

Your new microKEY serves double-duty as a USB hub. The two USB ports (Type A) allow you to expand your custom control center by adding on a Korg nanoPAD or nanoKONTROL or any other USB device.

For more details, please visit the manufacturer's website.

KEY FEATURES

• 37 velocity-sensitive Natural Touch mini keys, proportioned for excellent playability
• Octave Shift and Key Transpose features access the full MIDI note range
• Pitch Bend and Modulation wheels add expression to your performance
• USB powered with additional USB Hub connection

COMES WITH

• the Korg Kontrol Editor software, plus an additional software Bonus pack to get you started

OVERVIEW

The MPK25 is a portable keyboard controller with MPC production controls. Based closely on the MPK49, the first keyboard ever to feature MPC pads, the MPK25 scales down the keyboard by 24 keys and retains the utility, capability, and flexibility that made the MPK49 a Lab best seller. Its smaller, more portable size makes the MPK25 the perfect travel companion for producers on the go.

FEATURES

MPK25 combines a 25-key keyboard and 12 genuine MPC pads. The keyboard is semi-weighted and features aftertouch for expressive melodic control. The MPC pads are pressure and velocity-sensitive to capture every nuance of your creative concepts. The pads can access four banks of sounds, so you have 48 samples at your fingertips with the touch of a button.

MPK25 places dedicated transport controls within your reach for easy control of some of the most important tracking and editing controls. The MPK25 has modulation and pitch-bend wheels for expressive musicality, and two assignable footswitch inputs enable you to connect an expression pedal or other continuous controller and a footswitch for momentary controls like patch change or start/stop.

One of the most important input devices on an MPC is its Q-Link assignable control section. The MPK25 gives you twelve virtual knobs and four virtual buttons that are assignable to control nearly any software parameter. You can control two different parameters per Q-Link thanks to the knobs' dual-bank selection.

Two technologies pioneered in the MPC series and built into the MPK series are MPC Note Repeat and MPC Swing. These note-modifying features can be heard in many of the most popular tracks over the last two decades. MPC Note Repeat is a capability that enables the MPK (or MPC) to automatically play a rhythm pattern, such as 16th notes on a hi-hat, for accuracy and speed of entry. MPC Swing is sometimes referred to as "the heart and soul of hip hop" because it turns perfectly aligned sequences into human feeling time alignments. You can specify exactly the degree and timing of swing you want to apply for the perfect feel.

On top of MPC technologies, the MPK25 has its own arpeggiator, which enables you to create quick, creative riffs in seconds.

MPK25 also has MPC Full Level and MPC 12-Level on its pads, as well as Tap Tempo and Time Division so you can nail the tempo, timing, and dynamics exactly as you hear them in your head.

The MPK25 is a MIDI controller that sends its MIDI values over USB. It is bus powered, so all you need to connect and power the MPK25 is the supplied USB cable. Because it is MIDI compliant, the MPK25 works with most MIDI recording, sequencing, and performance software for musical performers from keyboard players to producers to DJs and even VJs. Includes Ableton Live Lite Akai Edition so you can begin producing right out of the box. Recommended.

KEY FEATURES

• 25-key semi-weighted keyboard with aftertouch for expressive melodic creativity
• MPC-pad section of 12 genuine MPC pads with pressure and velocity sensitivity
• MPC pads access four banks each for instant access to 48 samples
• Assignable Q-Link controller section for flexible control of most software parameters
• Two banks of 12 Q-Link knobs and four buttons, two banks each
• Dedicated transport controls for tracking and editing
• MPC Note Repeat, MPC Swing, and arpeggiator aid in creative process
• MPC Full Level, MPC 12-Level, Tap Tempo, and Time Division assist with tempo and dynamics
• MIDI output over USB, bus powered, class compliant: plug and play with one USB cable
• Comes with Ableton Live Lite Akai Edition software
• Works with most MIDI recording, sequencing, and performance software

COMES WITH

• Ableton Live Lite Akai Edition software
• USB cable
• Software CD
• Quick Start guide

OVERVIEW

Akai's LPK25 is a compact USB-MIDI controller keyboard for producers, musicians, and DJs. A scaled-down relative to the MPK series of keyboard performance controllers, the LPK is feature loaded allowing users to create melodies and riffs anywhere, plus its small size and weight makes it extremely portable.

FEATURES

The LPK25 keyboard is made up of 25 miniature, velocity-sensitive keyboard keys with synth action. It features an arpeggiator, which steps through chords automatically, assisting musicians with creating quick melodic ideas. Sustain, octave up and down and tap tempo controls round out the LPK25's easy-to-learn layout. The LPDK25 works plug and play with Mac and PC and requires no software driver installation or wall power for operation. It has four memory banks for programming and recalling settings appropriate to different software programs you use.

OUR OPINION

The LPK25 is a vast improvement on KORG's portable mini-USB keyboard. Whereas the KORG had "key-like' computer keys, the LPK25 actually has real mini-keys that are velocity sensitive. A must for keyboard players and producers who want to work with software need to express with real feeling keys. The added features of arpeggiator and memory make this a steal for under $70. Recommended.

KEY FEATURES

• USB-MIDI controller works with virtually all audio software
• 25 velocity-sensitive mini-keyboard keys
• Arpeggiator, sustain button, octave up and down, and tap tempo controls
• Plug-and-play USB connection for Mac and PC requires no driver installation
• Small enough to fit in a backpack or laptop bag
• Four programmable memory banks
• Comes with editor software for Mac and PC
• USB bus powered - no additional power cable needed

COMES WITH

• USB cable

OVERVIEW

The MPD18 gives you the control feel of the MPC in a super-portable and affordable instrument. Plus with its compact footprint, it's easy to fit in any setup for producing in the studio, on the go, or for live performance.

FEATURES

The heart of the MPD18 is its bank of 16 velocity and pressure-sensitive MPC pads, an Akai Pro exclusive. You can access three different banks of sounds from the MPC pads for a total of 48 sounds at your fingertips. The MPD18 also borrows the MPC series' assignable Q-Link controllers, enabling you to control nearly any parameters in your software in real time. You get an assignable Q-Link fader for natural, hands-on control of your most-used parameters, and MPC Note Repeat enables you to quickly input patterns such as hi-hat parts or drum rolls. The MPD18 also has 16 configurable presets so you can program it for the way you work with different hardware and software.

The MPD18 sends MIDI information over its plug-and-play USB interface so you can use it with your Mac or PC without installing any drivers. The USB connection even powers the MPD18 so the included USB cable is all you need for portable production. The MPD18 can control nearly any MIDI software, as well as MIDI hardware, such as synths, sound modules, samplers, sequencers, drum machines, and more.

KEY FEATURES

• USB MIDI controller for production and performance
• MPC pads: bank of 16, velocity and pressure sensitive
• Three pad banks for a total of 48 sounds accessible from pads
• Q-Link assignable fader control
• MPC Note Repeat
• MIDI-over-USB interface
• MPC 16-Level and Full Level
• 16 configurable presets
• USB powered, requires no AC adapter

OVERVIEW

The LPD8 is an ultra-portable USB-MIDI controller featuring 8 light-up pads and 8 knobs you can assign to virtually any software parameter. With a slim profile weighing less than a pound and measuring less than 13" across, the LPD8 easily fits in your laptop case, backpack, or DJ bag for producing/performing on the go.

FEATURES

The LPD8 has eight orange light-up pads that are velocity sensitive for programming rhythmic or melodic parts. The pads can also send program-change information to software. Additionally, the LPD8 has eight assignable Q-Link knobs you can assign to virtually any parameters in their software for hands-on control and has four memory banks for programming and recalling settings appropriate to different software programs. Also includes a software editor for easy saving and changing of settings through your computer. Works plug and play with Mac or PC (no software driver installation or external power cord necessary).

OUR OPINION

As Akai's answer the Korg's Nano series, the LPD8 holds up very well and actually has a few advantages. While both feature ulra-slim profiles and portability, the LPD8 combines pads AND knobs in one unit (although the knobs are rather short) whereas you would have to buy 2 Nanos (the PAD and KONTROL) to get these features with Korg. It is also slightly shorter than the nanoPAD and features a nice matte finish with rounded corners. Recommended.

KEY FEATURES

• USB-MIDI controller works with virtually all audio software
• 8 backlit, velocity-sensitive drum pads can send note or program change
• 8 Q-Link knobs for controlling virtually any parameters in software
• Plug-and-play USB connection for Mac and PC requires no driver installation
• Small enough to fit in a backpack or laptop bag
• 4 programmable memory banks
• comes with editor software for Mac and PC
• USB bus powered - no additional power cable needed

OVERVIEW

Maschine combines the flexibility of computer-based music production with the ease of a groove box into one powerful creative tool. Utilizing onboard samples or your own audio files, Machine's unique combination of hardware and software not only ensures a fast and fun workflow, but lets you easily turn your ideas into professional productions.

FEATURES

With the Maschine package you get:

• intuitive hardware/MIDI controller
• built-in effects
• browser, sequence, and sampler

The hardware unit is both instrument and MIDI controller in one. Sixteen illuminated, velocity-sensitive pads form an interface to intuitively make beats, tweak sounds, create patterns and sequence whole songs with the powerful Maschine software. Two large, high-resolution displays with eight corresponding rotary encoders, buttons, and transport controls also integrate perfectly.

Maschine connects to your Mac or PC via USB 2.0 and comes loaded with over 5GB of production-ready sounds and patterns. Everything from fat drum kits to state-of-the-art synthesizer sounds and pristine acoustic instruments have been sampled, sliced and tagged for your convenience. The unit also features studio quality effects ranging from dynamics processors to beat-mashers and even mastering tools, all tweakable in real time via the hardware controller. You get 300 drum kits, 280 multi-sampled instruments, 400 sliced loops, 6,500 one shots, 50 complete projects, and 100 effects. Maschine's pattern-oriented concept frees you from the limits of linear arrangement. Build song "scenes" by layering patterns, and re-arrange the scenes on the fly. It also offers external sampling through your computer's audio interface as well as internal re-sampling, precise editing and slicing, auto-mapping, effects and an ultra-convenient browser; all perfectly attuned to the hardware controller.

KEY FEATURES

• integrated computer based production studio
• combines intuitive sequencer, sampler and over 20 high-quality effects with real-time control and flexible routing into an inspiring Groove Production Studio
• dedicated controller with 16 high-quality pads, 41 buttons, and 11 rotary encoders for playing, recording, sequencing, automation and arrangement
• MIDI I/O
• fastest workflow with pattern-based arrangement and perfect hardware, software and host environment integration
• sstep sequencing, real-time recording, note repeat, slicing, and auto-mapping for intuitive jamming
• over 5 GB of inspiring, studio-quality sounds with over 15,000 samples and hundreds of patterns perfectly
• extensive MIDI-mapping capabilities to control other hardware and software
• easy-to-use browser with tagging of kits, instruments, samples, and effects Intuitive automation recording and step automation editing
• sampling from external and internal sources with threshold detection
• works as a plug-in for any software sequencer supporting VST, AU, or RTAS
• USB 2.0

COMES WITH

• maschine hardware
• maschine software

LAB POINTS

• ultra compact dj controller w/ built-in audio interface
• 2 channels w/ 4 deck control
• MIDI output for compatibility with most DJ software
• convenient laptop dock keeps screen in view while using controls
• built in effects & filter
• 4 hot cues per deck
• sampler & loop functions
• pulse control function uses LED lights to highlight what features are in play, beat matching accuracy and which track is loaded
• includes Virtual DJ Limited Edition software
• compatible with Serato DJ Intro (free download)

MANUFACTURER'S REVIEW

The DDJ-ERGO-V brings simplicity into both setup and performance, without compromising sound quality or features. Portable dimensions and sharp styling are complemented by a single bus powered cable connection to your laptop. All major controls and effects are intuitively positioned and ready on the first press of a button. Quick access features include 4-deck control, filters, FX, Hot Cues and sample banks with loop sampling too.

The DDJ-ERGO-V comes bundled with Atomix Productions Virtual DJ Limited Edition, that lets you scratch, mix and add modern remix effects to your music and video sets without paying for an upgrade. On top of the 4 decks with autosync, you get instant access to 8 samples, smart loops and much more. Automatic beatgrids, high-detail waveforms and a software interface that matches the controller will make it easy to keep track of the mix. Pulse Control uses lights to highlight what features are in play, how accurate your beat matching is and which track is loaded.

UPDATE: The DDJ-Ergo is now compatible with Serato DJ Intro (free download online)

Pioneer DDJ-ERGO-V Controller with Serato DJ Intro Software:

• Matching Hardware Layout: Serato DJ Intro is a simple two-channel mixing computer software application designed to work intuitively with the DDJ-ERGO-V's two players and two-channel mixer setup. The controller offers a user-friendly layout and features HOT CUE, samplers and effects.
• Easy to Read Graphic User Interface (GUI) - The DDJ-ERGO-V enables users to slide the keypad of their laptops under the controller for easy viewing of the GUI displayed on the computer screen. The new Serato DJ Intro software displays large color-coded waveforms for each musical instrument on its GUI, providing users with a visual progression of the music, ideal for any DJ skill level.
• Plug-and-Play USB Connectivity - The combined controller and Serato DJ Intro software via a USB connection provides instant audio playback that requires no other settings

KEY FEATURES

• USB controller w/ MIDI
• 2 channels, 4 deck control
• inputs: 1x 1/4" Mic, 1x RCA Aux
• outputs: 1x 1/4" Master Out, 1x RCA Master Out, 1x 1/4" Headphone Out, 1x Stereo Mini Headphone Out
• effects: flanger, beatgrid, flippin double, backspin, brake
• filter: high & low pass
• 4 hot cues per deck
• sampler
• autoloop & manual loop
• pro 115mm jog wheel
• pulse control: mix, beat, launch, fx
• laptop dock
• Windows Requirements: Windows XP (SP3)/Vista/7, Intel Pentium 4 or AMD Athlon XP, 512 MB RAM or more
• Mac OS X 10.5/10.6/10.7: Intel processor platform, 1024 MB RAM or more, 50 MB or more free disk space, 1024 x 768 screen resolution or more
• additional requirements for video mixing: ATI or NVIDIAR video chipset, dedicated 256MB DDR3 RAM Video

COMES WITH

• Virtual DJ Limited Edition Software

LAB POINTS

• all-in-one professional 2 deck controller
• includes Traktor Pro 2
• intuitive hardware built by the same team who made the Kontrol S4
• hot cue buttons & powerful looping features for on the fly remixing/editing
• sample knobs lets you mix up to 8 Sample Deck slots into your mix
• two flexible FX units give access to 30 BPM-syncable pro effects
• rugged and portable construction

MANUFACTURER'S REVIEW

TRAKTOR KONTROL S2 is the most professional 2-deck controller on the market. With pro credentials throughout, the 2.1 design couples the most essential items for any DJ - 2 decks and a mixer - with controls for multi-effect units and a third channel for samples. Set it up in an instant and dive right into the mix.

Rugged and highly portable, TRAKTOR KONTROL S2 is the only controller of its size to come with the full version of TRAKTOR PRO 2 included - the same software that pro DJs of all genres use. With TRAKTOR 2 Technology Inside, the S2 is tuned for maximum intuitiveness and creativity _ǫ" resulting in an intensely fluid and fun mixing experience.

This compact and portable unit was built by the same team and with the same components that brought you the TRAKTOR KONTROL S4 - the wildly-popular market-leader that revolutionized the all-in-one DJ system. Robust knobs and backlit buttons let you know what's going on at all times. Two high-quality, pressure-sensitive jog wheels deliver total track control and easy pitch bending and tempo nudging.

There's no steep learning curve with the S2 - the perfect integration between hardware and software means everything is ready to go, so you can focus on selecting the hottest tracks from your hard drive or iTunes library. Get deep into the powerful looping features, and use the four dedicated "hot-cue" buttons to effortlessly remix and re-edit tunes on the fly - all perfectly in time.

The Samples knob lets you mix the eight Sample Deck slots into your mix - either record loops from the playing track or use any of the included sound content. Two flexible FX units give you access to 30 pro effects that automatically sync to tempo, so you can easily stamp your own style on the mix.

TRAKTOR KONTROL S2 is the ideal hardware for new DJs who want to access the same great features used by the pros in an easily accessible and focused format.

KEY FEATURES

• 2 channel control plus 1 sample deck channel
• 44.1,48/88.2/96kHz sample rate
• 16 or 24-bit resolution
• Mic input
• 4x Audio Outputs (D/A), balanced 1/4" outputs, unbalanced RCA outs, & headphone out
• System Requirements: Windows XP (latest Service Pack, 32 Bit) or Windows Vista (latest Service Pack, 32/64 Bit) or Windows 7 (latest Service Pack, 32/64 Bit), Intel Pentium 4 2.4 GHz or Intel Core or AMD Athlon 64, 2 GB RAM / Mac OS X 10.6 (latest update) or 10.7, Intel Core Duo, 2 GB RAM / USB 2.0 port, DVD drive, 500 MB free disk space

COMES WITH

• Traktor Pro 2 software

LAB POINTS

• plug and play USB connectivity with 4-channel deck control
• includes TRAKTOR Pioneer DDJ-T1 Edition DJ Software
• premium built-in sound card, optimized for highest quality sound
• controller layout and software interface are identical, ensuring ease-of-use
• computer dock allows a laptop keyboard to slip directly under the controller, eliminating need for laptop stand
• P-LOCK Fader Cap lock mechanism design

MANUFACTURER'S REVIEW

The DDJ-T1 offers the same operability and layout as our pro-DJ equipment, whilst enabling DJs to play music files from the computer via dedicated TRAKTOR DDJ-T1 edition software (included). A Plug and Play connection via USB and a space for laptop keyboards under the controller that places the screen in the DJ's line of sight at all times, make the DDJ-T1 the perfect home or mobile DJ set-up. The controller's layout inherits tried and tested Pioneer functionality, offering excellent operability. And the effect area exactly mirrors the software interface, delivering the same look and feel.

A 115 mm jog wheel, 4-channel deck control (with a master/sync button to match song speed and tempo), 6 effects and recording help you unlock the full potential of the software at no extra cost. Other performance features include loop editing and quantising functions. Optimised audio circuitry in the master output area, borrowed from Pioneer pro-DJ equipment, ensures high quality sound that has beaten the competition hands down in listening tests. This, coupled with audio characteristics optimised for TRAKTOR software, ensure superior sound delivery.

All buttons are pre-assigned to the software functions, and the controller can be connected to the computer via USB cable, meaning DJs can truly "Plug and Play". The DDJ-T1 can also be powered by the USB port of a computer. The device adopts Pioneer's "P-LOCK Fader Cap," designed to prevent the fader caps from slipping.

KEY FEATURES

• 4 deck control
• premium built-in soundcard
• MASTER OUT x 2 (XLR and RCA)
• HEADPHONE OUT x 2 (1/4" and mini)
• MIC IN x 2 (1/4" front & back)
• AUX IN x 1 (RCA)
• compatible with Mac OS X 10.5 or later, Windows 7 Home Premium/Professional/Ultimate, Windows Vista Home Basic/Premium/Ultimate, XP Home Edition Professional
• NOT compatible with Windows XP Professional X64 edition
• dimensions: 26.8" x 3.7" 12.5"
• Weight: 10.8lbs.

COMES WITH

• Traktor DDJ-T1 Edition Software
• AC adaptor

LAB POINTS

• robust controller w/ plug and play USB connectivity
• includes Serato ITCH DJ Software
• premium built-in sound card, optimized for highest quality sound
• controller layout and software interface are identical, ensuring ease-of-use
• computer dock allows a laptop keyboard to slip directly under the controller, eliminating need for laptop stand
• P-LOCK Fader Cap lock mechanism design

MANUFACTURER'S REVIEW

The DDJ-S1 offers familiarity, innovation and pure controllerism to maximize performance with Serato ITCH software (which is included). A Plug and Play connection via USB, a unique XLR input/output to connect directly to professional PA equipment, and a microphone talk-over feature makes the DDJ-S1 the perfect home or mobile DJ set-up. The space for laptop keyboards under the controller eliminates set-up issues, and places the screen in the DJs line of sight at all times.The controller's layout inherits tried and tested Pioneer functionality, offering excellent operability. The controls include an alphabetic search function for quick song selection and a slip mode for momentary looping, reversing and scratching without losing the song position on return. A dedicated effect control area allows you to add Serato ITCH DJ FX to your mixes, while the master and channel level meters allow you to monitor while adjusting the volume. A Playing Address feature displays track progression on an LED display, while the needle search function allows DJs to quickly skip through a song to a preferred playback point.

Optimised audio circuitry in the master output area, borrowed from Pioneer pro-DJ equipment, ensures high quality sound that has beaten the competition hands down in listening tests. This, coupled with audio characteristics optimised for Serato ITCH software, ensure superior sound delivery. All buttons are pre-assigned to the software functions, and the controller can be connected to the computer via USB cable, meaning DJs can truly "Plug and Play". The DDJ-S1 can also be powered by the USB port of a computer.

KEY FEATURES

• 2 deck control
• premium built-in soundcard
• proprietary P-lock Fader cap design
• MASTER OUT x 2 (XLR and RCA)
• HEADPHONE OUT x 2 (1/4" and mini)
• MIC IN x 2 (1/4" front & back)
• AUX IN x 1 (RCA)
• compatible with Mac: OS X 10.4.11 or later with Intel processor
• Windows 32-Bit: 7 / Vista: Intel processor, 1.8GHz Core 2 Duo; 2GB RAM Windows XP: Intel processor, 1.8GHz Core 2 Duo; 1GB RAM
• Windows 64-bit: Vista: Intel processor, 2.2Ghz Core 2 Duo; 4GB RAM Windows 7: Intel processor, 2.4GHz Core 2 Duo; 4GB RAM Professional
• dimensions: 26.8" x 3.7" 12.5"
• weight: 10.8 lbs.

INCLUDES

• Serato Itch DJ Software
• AC adaptor

LAB POINTS

• integrated 4-deck Traktor controller w/ 4-channel mixer & 2 high-res jog wheels
• built-in high-end audio interface
• 2 analog inputs for hooking up external gear (turntables, CD players, etc)
• includes TRAKTOR PRO S4 software
• intuitive design
• plug & play

MANUFACTURER'S REVIEW

TRAKTOR KONTROL S4 was designed from its conception as a fully integrated system where software and hardware are fused in perfect harmony. Once you experience it, you'll immediately feel how simple, yet powerful and fluid a professional DJ system can be. TRAKTOR KONTROL S4 is the culmination of a 10-year vision and experience only Native Instruments can provide. So whether you're a seasoned TRAKTOR user looking for the ultimate controller, or just entering the world of digital DJing, the S4 delivers like no other can.

Custom-tailored for TRAKTOR, the S4 fuses a premium-quality 4 channel DJ mixer, a built-in 24 bit/96 kHz soundcard, an intuitive controller, and the flagship TRAKTOR PRO S4 software into one fully professional solution - the ideal one-stop package for DJs who want pro features, instant usability and go-anywhere portability.

The sleek, stylish controller puts TRAKTOR at your fingertips - fusing hardware and software into one harmonic unit. Innovative Sample Decks, high-quality electromagnetic jog wheels, two effect units and two clearly laid-out deck control sections can be assigned to any of the four software decks and deliver a new level in creative control over your one shots, tracks and loops.

The intuitive and ergonomic controller layout and its robust rotary knobs provide precise visual and tactile status feedback - perfect for any DJ situation. Highly responsive to the touch, TRAKTOR KONTROL S4 is incredibly smooth to use, while its slim and compact profile makes it easy to transport from gig to gig.

It's super simple to get straight in the mix, thanks to the included TRAKTOR PRO S4 software, adapted from the pioneering TRAKTOR PRO. Developed in perfect synergy with the S4's controller, new features have been added to the TRAKTOR PRO S4 software to fully take advantage of this all-in-one solution, while premium ready-made and instantly combinable loops have been provided by the renowned Loopmasters sample house.

TRAKTOR KONTROL S4 boasts a full featured 4-channel mixer section with sturdy faders, CUE buttons, illuminated level meters, high-quality 3-band EQs and a filter control knob on each channel. The filter is switchable between Traktor and Xone-style. The ergonomic layout has been created by DJs for DJs, with some of the world's biggest names having direct input in to the design. It's easy to integrate other DJ and performance gear like turntables, CD players or a microphone via the inputs.

The innovative new Loop Recorder feature acts like a fifth deck, to add an exciting layer on top of your mix by recording and looping audio on-the-fly. An optional foot controller can be used to engage the Loop Recorder while both hands are busy - for instance while performing an advanced scratch routine!

TRAKTOR KONTROL S4 also includes a powerful and versatile audio interface. With the same build quality as all multi-award winning Native Instruments DJ sound cards, this unit lets you easily integrate external turntables and CD players, instruments, MIDI gear, effects and a microphone into your TRAKTOR DJ sets.

Incorporating high-end AD/DA converters, hi-gain balanced 1/4" TRS outputs and an ultra-wide frequency response, TRAKTOR KONTROL S4's integrated audio interface provides all the power, clarity and dynamic range that modern DJs demand.

KEY FEATURES

• Highly integrated 4-deck TRAKTOR controller and flagship software
• Plug & play - all you need to start mixing is your computer and MP3s
• Hardware: 4-channel mixer with ergonomic layout, 2 high-res touch-sensitive jog wheels
• Built-in high-end 24-bit/96kHz low-latency audio interface with Cirrus Logic AD/DA converters and MIDI I/O
• 2 analog inputs with phono and mic preamps for hooking up turntables, CD players or external audio gear; RCA mic in, balanced 1/4" TRS and unbalanced RCA master out
• Software: TRAKTOR PRO S4 - pro features, supreme usability; features 4-deck mixing and effects, plus all-new Sample Decks and a powerful Loop Recorder
• Industry-leading TRAKTOR engine ensures perfect sync and tight mixing
• 2 customizable FX sections with over 25 performance effects for adding your own trademark sound
• Powerful MP3 management with iTunes integration and iPod compatibility
• Intuitive design, ready-made sample content and tutorial videos make it easy for new users to get started

OVERVIEW

Native Instrument's TRAKTOR KONTROL X1 is the first official TRAKTOR controller for use with any DJ software. Whether you are a DVS timecode or software DJ, simply connect the TRAKTOR KONTROL X1 to a computer running TRAKTOR (or other performance software) and gain instant control of your decks and effect parameters. Robust rotary knobs with a heavy-duty feel and backlit buttons provide precise visual and tactile status feedback - letting you delve deep inside your program without having to touch your computer.

FEATURES

TRAKTOR KONTROL X1 features bi-directional communication with TRAKTOR via Native Instruments' high resolution protocol gives the hardware a smoother and more precise feel compared to regular MIDI controllers. All buttons and knobs have been pre-mapped for optimum TRAKTOR use but can be re-configured in any way you like. TRAKTOR KONTROL X1 can also be used as a MIDI controller for any software as well as expanded with a second unit to control four decks and four FX units. The unit is plug and play (meaning you don't need to install any drivers) and features a total of 8 knobs, 8 buttons, loop and control section all in a lightweight, slim housing. TRAKTOR KONTROL X1 also comes with a powerful selection of software to get you mixing and making music straight out of the box. The included software consists of the following: Traktor LE and Kore 2 Player/Instrument.

KEY FEATURES

• Designed by the creators of TRAKTOR for perfect software integration
• Plug and play - instant recognition by TRAKTOR with no setup required
• Precision designed high-end buttons, knobs and encoders
• Software controlled backlit buttons for comprehensive visual feedback
• Lightweight, robust housing with slim, ultra-portable form factor - fits perfectly alongside a standard club mixer
• Super-intuitive loop and cue control section
• 8 knobs and 8 buttons for simultaneous access to all effect parameters of both decks
• Push encoders for browsing and loading tracks to each deck instantly
• Expandable - connect two X1s to control four decks
• Compatible - includes MIDI templates for controlling other DJ and performance software
• Seamlessly adjustable LED brightness adapts to any environment from bright daylight to the darkest club
• Button off glow for reading button labels in absolute darkness
• Bi-directional communication with TRAKTOR using NHL (Native Hardware Library)

COMES WITH

• Traktor LE software
• Kore 2 Player/Instrument

LAB POINTS

• versatile USB MIDI control surface
• 81 programmable backlight buttons w/ bi-directional MIDI communication (talk back)
• plug & play USB, no drivers required
• sturdy aluminum body, handsome mahogany end pieces
• open source software tools to custom edit talk back communication
• standard MIDI I/O and expansion jacks
• Ohm editor included

MANUFACTURER'S REVEIW

The OhmRGB is a totally customizable, interactive MIDI instrument, designed to give you hands-on control for your performance. High-quality sliders, knobs buttons, expansion jacks, and multicolor LEDs provide the interface for creative expression, whether you're mixing samples and synths or DJ'ing a cutting-edge set. Constructed with anodized aluminum and hand-finished wood, the quality is felt down to your fingertips. All of our controllers are proudly hand crafted and assembled for artists by artists in our Austin, Texas shop.

The OhmRGB has bi-directional talkback for communication between the controller and your software. Up to seven colors can be used to create customized layouts and show different states. It's completely USB powered so you don't have to worry about adapters or power strips. It's plug-and-play, so no drivers are required. Expansion jacks lets you add up to eight additional analog controls and two expression pedals to get your feet mixing too. The OhmRGB works with any software that supports midi and templates are available for many popular softwares such as Ableton Live, Native Instruments Traktor, Propellerhead's Reason and Record, Max/MSP, Max for Live, Renoise, MLRV2, Luminair, Cell DNA, and Arkaos Grand VJ.

KEY FEATURES

• USB Powered, customizable controller
• Multicolored LEDs with Bi-Directional MIDI communication (talkback)
• Class-compliant: no drivers needed for Mac, Windows, or Linux
• 81 Programmable backlight buttons for talk-back and interactive performance
• Programmable MIDI mapping allows you to change the MIDI settings on the hardware
• Aluminum Body
• Mahogany Wood endcaps
• Open Source software tools to create your own LED talkback interaction
• Ohm Editor included for MIDI editing, and LED talkback programming
• Standard MIDI IN and OUT jacks
• Expansion Jacks for added functionailty
• Made in the USA
• Compatible with any software that supports MIDI learn
• 16.5" x 9.5" x 1.75" (WDH) / weight 6 lbs

COMES WITH

• USB cable and registration card

LAB POINTS

• stylish and versatile MIDI control surface
• 32 endless knob encoders with LED rings + 45 buttons
• fully programmable MIDI mapping, bi-directional MIDI communication
• includes Editor software
• USB bus-powered

MANUFACTURER'S REVEIW

Code is a flexible and stylish control surface for computer music creation and performance. Its compact grid of 32 endless encoders with LED rings have built-in pushbuttons with addressable LEDs let you "think outside the grid." Code sends and receives MIDI, providing endless possibilities for use with software such as Ableton Live, Max/MSP, Properllerhead's Reason and Record, and NI Traktor, just to name a few. Class-complaint, bus-powered, and completely reprogrammable, Code is an ideal companion to hardware and software for music production. Open source firmware (licenced under GPL v3) provides developers with new avenues of exploration and the potential for users to try out different configurations.

Weighing in at only 2 lbs and 6" x 11" x 2" (WDH), Code is extremely portable and adaptable, so it will easily integrate with your existing hardware and software. Each encoder on the Code has an LED indicator ring that provides visual feedback on its position. Every encoder also works as a push button and has an LED indicator button below knob, opening up creative possibilities for use as a grid controller and knob controller at the same time. The minimal design and adaptability of Code make this controller a true instrument. Code is crafted at our facility in Austin, TX from sleek anodized aluminum with hand finished mahogany sides for style and performance.

KEY FEATURES

• 6" x 11" x 2" (WDH) / weight 2 lbs.
• USB Powered
• Bi-Directional MIDI communication (talkback)
• Class-compliant: no drivers needed for Mac, Windows, or Linux
• 34 Programmable encoders, and 45 buttons for talk-back and interactive performance
• Programmable MIDI mapping allows you to change the MIDI settings on the hardware
• Aluminum and mahogany construction
• Open Source software tools to create your own LED talkback interaction
• Editor included for MIDI editing, and LED talkback programming
• Standard MIDI IN and OUT jacks
• Made in the USA
• Compatible with any software that supports MIDI learn
• ROHS compliant

COMES WITH

• USB cable

MANUFACTURER'S REVIEW

This is the ME version of the Block that now features all metal aluminum enclosure with hand finished mahoghany ends. Block is a compact and programmable MIDI control surface designed for interactive audio performance built on the same bi-directional and adaptable platform as the Ohm64. Block provides a powerful interface for creating and interacting with sound in a small easy-to-transport body.

Sixty four backlight led buttons provide endless possibilities for visual feedback with the instrument by connecting it to Ableton Live, Max/Msp, our open source sounds apps, or any other software that supports MIDI. The open source blockEditor application lets you reprogram any of the controller's sixty four clip buttons, eight knobs, two faders, and seven function buttons. Block has bi-directional talkback communication allowing the controller to talk to your software, and software to your device. MIDI messages can be sent to the Block to light up the buttons for an interactive performance. Completely programable and mappable, block provides a flexible control surface that be used with any software or setup. Completely USB powered means you don't have to worry about adapters and and power strips, and it is plug and play so no drivers are required. Block is hand crafted from lightweight wood and aluminum for easy portability.

KEY FEATURES

• Bi-Directional MIDI communication (talkback)
• 64 Programmable backlight buttons for talk-back and interactive performance
• Programmable MIDI mapping allows you to change the MIDI settings on the hardware
• Anodized Aluminum Body with Mahogany ends
• Open Source software tools to create your own LED talkback interaction
• Editor included for MIDI editing, and LED talkback programming
• Made in the USA
• Compatible with any software that supports MIDI learn
• Class-compliant: no drivers needed for Mac, Windows, or Linux
• ROHS compliant
• USB cable included
• 10" x 9.5" x 2" (WLH) / weight 3 lbs
• USB Powered

LAB POINTS

• updated MKII version with built-in sound card, 4 deck control, and tension adjustable JOG wheels
• all-in-one hardware + software digital djing system, all you need is a computer and headphones
• includes Traktor LE
• built-in 16bit/44.1kHz audio interface, no need for additional interface
• 2 RCA in and 4 RCA out enables you to add CD players, turntables, and effects to your setup
• large high resolution JOG wheels
• new joystick for speedy track searching & loading
• dedicated USB MIDI controller, up to 128 MIDI assignable parameters
• durable and lightweight, only 4.4 pounds

LAB REVIEW

This is the updated MKII version. The main differences between MKI and MKII are the addition of the built-in 2 in/4 out audio interface (which eliminates the need for additional interfaces and allows for addition of CD players, turntables, samplers and effects to your DJ setup), 4 deck control, and larger, tension adjustable JOG wheels. Additional upgrades include a new multi-function joystick for quick and easy searching and loading of tracks, more MIDI assignable parameters (128 total), new ergonomic knobs, and a new symmetrical control layout. These upgrades make the VCI-100 almost on par with the VCI-300, but includes Traktor LE instead of Serato Itch and lacks mic input and 1/4" outs. The addition of the built-in interface is huge in making the unit a true all-in-one system, plus the option to control 4 decks, quick search joystick, and lightweight design make the VCI-100MK2 an excellent choice for digital DJs. Recommended.

HIGH QUALITY AUDIO

The VCI-100MK2 includes a high quality 16bit/44.1kHz 2in4out audio interface which enables to add CD players, turntables, effects, samplers, and more to your DJ setup. Also considering DJs who want to have options, the VCI-100MK2 can also be used with other audio interfaces.

4 DECK CONTROL

Mix maximum 4 decks by switching through with the DECK selector.

TORQUE CONTROL

Every DJ has a preference for the touch of the JOG wheel, which relates to the DJ's play style. The rotation torque of the VCI-100MK2's JOG wheels can be tuned to your preference by simply adjusting the centerpiece.

REFINED CONTROL

All buttons of the VCI-100MK2 are tuned to provide a stress less refined touch and communicate with extreme precision. LED backlights provide excellent visibility and tells you the current status of your setup.

ALUMITE PANEL

The strong and solid alumite (the same aluminum type material used on macbooks) top panel secures the VCI-100MK2 and provides a professional appearance. Just looking at it tells you it will live up to heavy duty.

KEY FEATURES

• works with MAC and PC, please see manufacturer's link for specific computer requirements
• USB bus-power or powered by optional SDC-7 adaptor
• (4) RCA master outputs
• (2) RCA inputs
• (1) headphone output
• crossfader with curve control
• 14.4" x 10.6"(L) x 1.5"(H), 4.4 lbs

COMES WITH

• Owner's Manual
• Traktor LE Software CD
• Driver Install CD (ASIO4VCI-100MKII)
